Panasonic Lumix DMC-FT25 User Manual

- 18 -
Preparation
∫ Recording still pictures
Recording conditions by CIPA standard
•
CIPA is an abbreviation of [Camera & Imaging Products Association].
• Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on.
• Using a Panasonic SD Memory Card (32 MB).
• Using the supplied battery.
• Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabiliser
function is set to [ON].)
• Recording once every 30 seconds using full flash every second recording.
• Changing the zoom magnification from Tele to Wide or vice versa in every recording.
• Turning the camera off every 10 recordings and leaving it until the temperature of the battery
decreases.
The number of recordable pictures varies depending on the recording interval time. As
the recording interval time becomes longer, the number of recordable pictures
decreases. [For example, if you were to take one picture every two minutes, then the
number of pictures would be reduced to approximately one-quarter of the number of
pictures given above (based upon one picture taken every 30 seconds).]
∫ Recording motion pictures
When recording with picture quality set to [HD]
•
These times are for an ambient temperature of 23 oC (73.4 oF) and a humidity of 50%RH. Please be
aware that these times are approximate.
• Actual recordable time is the time available for recording when repeating actions such as turning this
unit on and off, starting/stopping recording, zoom operation, etc.
• Maximum time to record motion pictures continuously is 29 minutes 59 seconds. The maximum
available recording time continuously is displayed on the screen.
Approximate operating time and number of recordable pictures
Number of recordable
pictures
Approx. 250 pictures
By CIPA standard in Normal
Picture Mode
Recording time Approx. 125 min
Recordable time Approx. 100 min
Actual recordable time Approx. 50 min

Panasonic Lumix DMC-FT25 Specifications

General

Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Lens type	Wide-angle
Optical zoom	4 x
Extra/Smart zoom	8 x
Focal length range	4.5 - 18 mm
Maximum aperture number	5.7
Minimum aperture number	3.9
Number of aspheric elements	5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	100 mm
Minimum focal length (35mm film equiv)	25 mm
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Auto Mode focusing range (tele)	1.00 - ∞ m
Auto Mode focusing range (wide)	0.50 - ∞ m
Light metering	Evaluative (Multi-pattern)
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Auto
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1300 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3 m
Flash range (wide)	0.3 - 4.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	25 fps
Video formats supported	MP4
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Product color	Black
Scene modes	Beach, Children, Cuisine, Night, Night landscape, Panorama, Pet, Portrait, Snow, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
Battery voltage	3.6 V
Battery capacity	680 mAh
Battery life (CIPA standard)	250 shots
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.0 SE\\r Adobe Reader

Weight and Dimensions

Depth	19.7 mm
Width	103.7 mm
Height	58.3 mm
Weight	125 g
Weight (including battery)	144 g
