Panasonic Lumix DMC-FT25 User Manual

- 71 -
Recording
∫ Technique for Panorama Shot Mode
•
The zoom position is fixed to Wide.
• The focus, white balance, and exposure are fixed at the optimum values for the first picture. As a
result, if the focus or brightness changes substantially during recording, the entire panorama picture
may not be recorded at the suitable focus or brightness.
• White Balance is fixed to [AWB] while an image effect is applied.
• When multiple pictures are combined to create a single panorama picture, the subject may appear
distorted or the connection points may be noticeable in some cases.
• The number of recording pixels in the horizontal and vertical directions of the panorama picture
varies depending on the recording direction and the number of combined pictures. The maximum
number of pixels is shown below.
• A panorama picture may not be able to be created, or the pictures may not be combined properly
when recording the following subjects or under the recording conditions below.
– Subjects with a single, uniform colour or repetitive pattern (such as the sky or a beach)
– Moving subjects (person, pet, car, waves, flowers blowing in the breeze, etc.)
– Subjects where the colour or patterns change in a short time (such as an image appearing on a
display)
– Dark places
– Locations with flickering light sources such as fluorescent lights or candles
∫ About playback
¢1 If you have filtered images for playback by using [Slide Show] (P99) or [Filtering Play] (P101), the
selection screen appears. Press 3/4 to select [Play Panorama], and then press [MENU/SET].
¢2 You can perform frame-by-frame forward/rewind by pressing
1/2 during a pause.
A Move the camera in the recording direction
without shaking it. If the camera shakes too
much, pictures may not be able to be
recorded, or the recorded panorama picture
may become narrower (smaller).
B Move the camera towards the edge of the
range you wish to record. (The edge of the
range will not be recorded in the last frame)
Recording direction Horizontal Resolution Vertical Resolution
Horizontal 3200 pixels 720 pixels
Vertical 960 pixels 3200 pixels
3 Start panorama playback
¢1
/Pause
¢2
4 Stop

Panasonic Lumix DMC-FT25 Specifications

General

Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	JPG
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Lens type	Wide-angle
Optical zoom	4 x
Extra/Smart zoom	8 x
Focal length range	4.5 - 18 mm
Maximum aperture number	5.7
Minimum aperture number	3.9
Number of aspheric elements	5
Lens structure (elements/groups)	11/10
Maximum focal length (35mm film equiv)	100 mm
Minimum focal length (35mm film equiv)	25 mm
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus, Tracking Auto Focus
Auto Mode focusing range (tele)	1.00 - ∞ m
Auto Mode focusing range (wide)	0.50 - ∞ m
Light metering	Evaluative (Multi-pattern)
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Auto
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1300 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3 m
Flash range (wide)	0.3 - 4.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	25 fps
Video formats supported	MP4
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Product color	Black
Scene modes	Beach, Children, Cuisine, Night, Night landscape, Panorama, Pet, Portrait, Snow, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
Battery voltage	3.6 V
Battery capacity	680 mAh
Battery life (CIPA standard)	250 shots
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.0 SE\\r Adobe Reader

Weight and Dimensions

Depth	19.7 mm
Width	103.7 mm
Height	58.3 mm
Weight	125 g
Weight (including battery)	144 g
