Before Use
Names of the Components
1 Flash (P37)
2 Lens (P5, 101)
3 Self-timer indicator (P41)
AF assist lamp (P66)
4 LCD monitor (P35, 98)
5 Status indicator (P14, 21, 25)
6 [MENU/SET] button (P16)
7 [DISPLAY] button (P35)
8 [Q.MENU] (P19)/Delete (P33) button
9 [REC]/[PLAYBACK] selector switch
(P17)
10 Cursor buttons
A: 3/Exposure compensation (P42)/
Auto bracket (P43)/White balance
fine adjustment (P61)
B: 4/Macro mode (P40)
AF Tracking (P26, 63)
C: 2/Self-timer button (P41)
D: 1/Flash setting button (P37)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
