Panasonic LUMIX DMC-FX40 - Names of the Components

VQT1X72 (ENG)
8
Names of the Components
1Flash
2 Lens
3 Self-timer indicator
AF assist lamp
4 LCD monitor
5 Status indicator
6 [MENU/SET] button
7 [DISPLAY] button
8 [Q.MENU]/Delete button
9 [REC]/[PLAYBACK] selector switch
10 Cursor buttons
A: 3/Exposure compensation/Auto
bracket/White balance fine
adjustment
B: 4/Macro mode/
AF Tracking
C: 2/Self-timer button
D: 1/Flash setting button
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
123
104 9
5786
