Preparation
26
VQT0R26
∫ Histogram
• A histogram is a graph that displays
brightness along the horizontal axis (black
to white) and the number of pixels at each
brightness level on the vertical axis.
• It allows the camera user to easily check
the way a picture is being exposed.
• It is very useful if manual adjustments of
the lens aperture and shutter speed are
available, especially in those situations
where automatic exposure may be difficult
due to uneven lighting. Using the
histogram feature will allow you to get the
best performance from the camera.
A When the values are concentrated to
the left, the picture is under exposed.
B When the values in the histogram are
distributed evenly, the exposure is
adequate and the brightness is
well-balanced.
C When the values are concentrated to
the right, the picture is over exposed.
Example of histogram
A Under Exposed
B Properly Exposed
C Over Exposed
¢Histogram
• When you take pictures with the flash
or in dark places, the histogram is
displayed in orange because the
recorded picture and the histogram do
not match each other.
• The histogram does not appear when in
simple mode [ ], motion image mode
[ ], during multi playback and playback
zoom.
• The histogram in the recording mode is an
approximation.
• The histogram in recording and playback
may not match each other.
• The histogram in the camera does not
match the one displayed in image editing
software used with a PC, etc.
100
_
0001
10:00 DEC. 1.2005
F2.8 1/200
100
_
0001
10:00 DEC. 1.2005
F2.8 1/100
100
_
0001
10:00 DEC. 1.2005
F2.8 1/50
ISO
100
AUTO
ISO
100
AUTO
ISO
100
AUTO
1/3
1/3
1/3
