Before Use
- 8 -
21 Shoulder strap eyelet (P18)
•
Be sure to attach the shoulder strap when
using the camera to ensure that you will not
drop it.
22 [REMOTE] socket (P184)
23 [HDMI] socket (P168)
24 [AV OUT/DIGITAL] socket (P168, 173, 176,
178)
25 Focus distance reference mark (P91)
26 Stereo microphone
27 Shutter button (P35)
28 Speaker (P64)
29 Flash open lever (P72)
30 Hot shoe (P182)
31 Mode dial (P30)
32 Status indicator (P28)
33 Intelligent Auto button (P38)
34 Tripod receptacle (P194)
35 DC coupler cover
•
When using an AC adaptor, ensure that the
Panasonic DC coupler (optional) and AC
adaptor (optional) are used. (P184)
36 Release lever (P24)
37 Card/Battery door (P24)
23
22
21
24
29 3332
25
27
313028
26
3534 36 37
