- 7 -
Before Use
16 Stereo microphone
17 Shutter button (P34)
18 Motion picture button (P44)
19 Focus distance reference mark (P92)
20 Hot shoe cover (P8, 188, 190)
21 Camera ON/OFF switch (P28)
22 Status indicator (P28)
23 Intelligent Auto button (P48)
24 Shoulder strap eyelet (P17)
•
Be sure to attach the shoulder strap when
using the camera to ensure that you will not
drop it.
25 [HDMI] socket (P171)
26 [AV OUT/DIGITAL] socket (P169, 177, 179,
182)
27 Tripod receptacle (P202)
•
When you use a tripod, make sure the tripod
is stable when the camera is attached to it.
If the attached lens contacts the base of the
tripod, use the tripod adaptor (DMW-TA1;
optional).
28 Card/Battery door (P24)
29 DC coupler cover
•
When using an AC adaptor, ensure that the
Panasonic DC coupler (optional) and AC
adaptor (optional) are used. (P191)
30 Release lever (P24)
