Before Use
- 8 -
15 Shoulder strap eyelet (P16)
•
Be sure to attach the shoulder strap when
using the camera to ensure that you will not
drop it.
16 [HDMI] socket (P164)
17 [AV OUT/DIGITAL] socket (P164, 169, 172,
174)
18 Microphone
•
Do not cover the microphone with your
fingers.
19 Shutter button (P33)
20 Motion picture button (P45)
21 Speaker (P64)
•
Do not cover the speaker with your fingers.
22 Focus distance reference mark (P91)
23 Intelligent Auto button (P35)
24 Camera ON/OFF switch (P26)
25 Status indicator (P26)
26 Tripod receptacle (P188)
27 Card/Battery door (P22)
28 DC coupler cover
•
When using an AC adaptor, ensure that the
Panasonic DC coupler (optional) and AC
adaptor (optional) are used. (P178)
29 Release lever (P22)
