Connecting to other equipment
∫ Copying to a PC without using “PHOTOfunSTUDIO”
If the installation of “PHOTOfunSTUDIO” fails, you can copy files and folders to your PC by
dragging and dropping them from the camera after connecting to your PC.
Directory structure of built-in memory/card of this unit is shown by the figure below.
•
A new folder is created when pictures are taken in the following situations.
–When a card containing a folder with the same folder number has been inserted (Such as when
pictures were taken using another maker of camera)
–When there is a picture with file number 999 inside the folder
∫ Disconnecting the USB connection cable safely
Select the [ ] icon in the task tray displayed on the PC, and then click [Eject
DMC-XXX] (XXX varies by model).
• Depending on your PC’s settings, this icon may not be displayed.
• If the icon is not displayed, check that [Access] is not displayed on the LCD monitor of the digital
camera before removing the hardware.
∫ Connection in the PTP Mode
Select [PictBridge(PTP)] when connecting USB connection cable.
•
Data can now be read only from the card in the PC.
• When there are 1000 or more pictures on a card, the pictures may not be imported in the PTP Mode.
For Windows: A drive ([Removable Disk]) is displayed in [Computer]
For Mac: A drive ([NO_NAME]) is displayed on the desktop
•
Built-in Memory
• Card
DCIM: Images
1 Folder number
2 File number
3 JPG: Still pictures
MOV: Motion pictures
MISC: DPOF print
Favorite
DCIM
100_PANA
101_PANA
999_PANA
MISC

Panasonic Lumix DMC-SZ3 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3456 x 3456 pixels
Still image resolution(s)	640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom	4 x
Optical zoom	10 x
Combined zoom	20 x
Extra/Smart zoom	22.5 x
Focal length range	4.5 - 45 mm
Maximum aperture number	5.9
Minimum aperture number	3.1
Lens structure (elements/groups)	9/7
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus
Macro focusing range (tele)	1.5 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.6 - 4.1 m
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	24 fps
Video formats supported	M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps
Audio system	Mono
Memory slots	1
Internal memory	90 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
HDMI	No
USB version	-
Product color	Black
Scene modes	Children, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source type	Battery
Accessories included	8GB SDHC
Battery voltage	3.6 V
Battery capacity	690 mAh
Battery life (CIPA standard)	250 shots
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	21.9 mm
Width	94.8 mm
Height	55.8 mm
Weight	111 g
Weight (including battery)	126 g
