Panasonic Lumix DMC-SZ3 Owner's Manual

- 104 -
Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to be
printed out and instruct that printing be started on the camera’s LCD monitor.
•
Some printers can print directly from the card removed from the camera. For details, refer to the
operating instructions of your printer.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures from the built-in memory.
Check print quality and other settings on the printer before printing the pictures.
1
Connect the printer and camera with the USB connection cable
(supplied).
2
Press 3/4 to select [PictBridge(PTP)], and then press [MENU/SET].
• If the remaining battery power becomes low while the camera and the printer are connected, the
alarm beeps. If this happens during printing, stop printing at once. If not printing, disconnect the USB
connection cable.
• Do not disconnect the USB connection cable while [å] (Cable disconnect prohibit icon) is displayed.
(may not be displayed depending on the type of printer used)
• Before inserting or removing a card, turn the camera off, and disconnect the USB connection cable.
• Motion pictures cannot be printed out.
• Check the directions of the connectors, and plug them straight in or unplug them straight
out. (Otherwise the connectors may bend out of shape, which may cause malfunction.)
• Do not use any other USB connection cables except the supplied one or a genuine
Panasonic USB connection cable (DMW-USBC1: optional).
A USB connection cable (supplied)
B Align the marks, and insert.

Panasonic Lumix DMC-SZ3 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3456 x 3456 pixels
Still image resolution(s)	640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom	4 x
Optical zoom	10 x
Combined zoom	20 x
Extra/Smart zoom	22.5 x
Focal length range	4.5 - 45 mm
Maximum aperture number	5.9
Minimum aperture number	3.1
Lens structure (elements/groups)	9/7
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus
Macro focusing range (tele)	1.5 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.6 - 4.1 m
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	24 fps
Video formats supported	M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps
Audio system	Mono
Memory slots	1
Internal memory	90 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
HDMI	No
USB version	-
Product color	Black
Scene modes	Children, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source type	Battery
Accessories included	8GB SDHC
Battery voltage	3.6 V
Battery capacity	690 mAh
Battery life (CIPA standard)	250 shots
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	21.9 mm
Width	94.8 mm
Height	55.8 mm
Weight	111 g
Weight (including battery)	126 g
