Panasonic Lumix DMC-SZ3 Owner's Manual

- 13 -
Preparation
• Do not leave any metal items (such as clips) near the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the resulting
heat generated.
• Do not use any other USB connection cables except the supplied one or a genuine Panasonic USB
connection cable (DMW-USBC1: optional).
• Do not use any other AC adaptors except the supplied one.
• Do not use a USB extension cable.
• The AC adaptor (supplied) and USB connection cable (supplied) are for this camera only. Do not use
them with other devices.
• Remove the battery after use. (The battery will be exhausted if left for a long period of time after
being charged.)
• The battery becomes warm after using and during and after charging. The camera also becomes
warm during use. This is not a malfunction.
• The battery can be recharged even when it still has some power left, but it is not recommended that
the battery charge be frequently topped up while the battery is fully charged. (Since characteristic
swelling may occur.)
• If a problem occurs in the power outlet, such as a power outage, charging may not be completed
normally. If this happens, disconnect the USB connection cable (supplied) and connect it again.
• If the charging lamp does not turn on or blinks when you connect the AC adaptor (supplied) or PC,
this indicates that the charging has been stopped because the unit is not in a temperature range
suitable for charging, and does not indicate a fault.
Reconnect the USB connection cable (supplied) in a location where the ambient temperature (and
the temperature of battery) is in a 10 oC to 30 oC (50 oF to 86 oF) range, and try charging again.

Panasonic Lumix DMC-SZ3 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3456 x 3456 pixels
Still image resolution(s)	640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom	4 x
Optical zoom	10 x
Combined zoom	20 x
Extra/Smart zoom	22.5 x
Focal length range	4.5 - 45 mm
Maximum aperture number	5.9
Minimum aperture number	3.1
Lens structure (elements/groups)	9/7
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus
Macro focusing range (tele)	1.5 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.6 - 4.1 m
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	24 fps
Video formats supported	M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps
Audio system	Mono
Memory slots	1
Internal memory	90 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
HDMI	No
USB version	-
Product color	Black
Scene modes	Children, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source type	Battery
Accessories included	8GB SDHC
Battery voltage	3.6 V
Battery capacity	690 mAh
Battery life (CIPA standard)	250 shots
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	21.9 mm
Width	94.8 mm
Height	55.8 mm
Weight	111 g
Weight (including battery)	126 g
