- 12 -
Preparation
The AC adaptor (optional) can only be used with the
designated Panasonic DC coupler (optional). The AC
adaptor (optional) cannot be used by itself.
1 Open the card/battery door.
2 Insert the DC coupler, being careful of the direction.
3 Open the DC coupler cover A.
•
Push open the coupler cover from the interior.
4 Close the card/battery door.
•
Ensure that the card/battery door is closed.
5 Plug the AC adaptor into an electrical outlet.
6 Connect the AC adaptor B to the [DC IN] socket C of
the DC coupler.
D Align the marks and insert.
• Ensure that only the AC adaptor and DC coupler for this
camera are used. Using any other equipment may cause
damage.
Note
•
Always use a genuine Panasonic AC adaptor (optional).
• Some tripods cannot be attached when the DC coupler is connected.
• Make sure to unplug the AC adaptor when you open the card/battery door.
• If the AC adaptor and DC coupler are not necessary, then remove them from the digital camera.
Also, please keep the DC coupler cover closed.
• Also read the operating instructions for the AC adaptor and DC coupler.
When using an AC adaptor, ensure that the Panasonic DC coupler (optional) and AC
adaptor (optional) are used.
