Preparation
• Charge the battery in areas with an ambient temperature, between 10 oC and 30 oC (50 oF and
86 oF) (same as the battery temperature), is recommended.
(Charging from the power outlet)
Connect the AC adaptor (supplied) and this camera with the USB connection
cable (supplied/optional), and insert the AC adaptor (supplied) into the power
outlet.
• Use the AC adaptor (supplied) indoors.
Charging
Check that this unit is turned off.
A To power outlet
B AC adaptor (supplied)
C PC (Turned on)
D USB connection cable (supplied)
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may bend out of shape, which may cause malfunction.)
E Align the marks, and insert.
F Charging lamp
