Names and Functions of Main Parts
1 Motion picture button
2 Shutter button
3 Camera ON/OFF switch
4Flash
5 Microphone
6 Speaker
• Be careful not to cover the speaker
with your finger. Doing so may make
sound difficult to hear.
7 Zoom lever
8Lens
9 Lens barrel
10 Self-timer indicator
AF Assist Lamp
11 LCD monitor
12 [MODE] button
13 Charging lamp
14 REC/PLAY switch
15 Strap eyelet
• Be sure to attach the strap when
using the camera to ensure that you
will not drop it.
16 Cursor buttons
17 [DISP.] button
18 [MENU/SET] button
19 [Q.MENU]/[ ] (Delete/Cancel)
button
20 [HDMI] socket
21 [AV OUT/DIGITAL] socket
22 Tripod receptacle
23 Card/Battery door
24 Release lever
1
10
789
24
1916 17
23 6
54
14 1511
22 23
12 13
18
20
21
