- 137 -
Others
Before cleaning the camera, remove the battery or the DC coupler (optional), or
disconnect the power plug from the outlet. Then wipe the camera with a dry, soft cloth.
When the camera is soiled badly, it can be cleaned by wiping the dirt off with a wrung wet cloth, and
then with a dry cloth.
Do not use solvents such as benzine, thinner, alcohol, cleanser, kitchen detergents, etc., to clean the
camera, since it may deteriorate the external case or the coating may peel off.
When using a chemical cloth, be sure to follow the accompanying instructions.
When salt etc., has adhered to the camera, the arm part of the side
door etc., may whiten. Use damp cotton swabs or similar to wipe
until the whitened part is removed.
A Arm part
Do not press the LCD monitor with excessive force. Uneven colors may appear on the LCD monitor
and it may malfunction.
If the camera gets very cold in cold places such as ski resorts or places at high altitude, performance
of the LCD monitor may temporarily drop immediately after turning this unit on, e.g. the picture on
the LCD monitor being slightly darker than usual or ghost images appearing. Keep the camera warm
when using in a cold environment. The performance will resume as normal when the internal
temperature rises.
Cleaning
About the LCD monitor
Extremely high precision technology is employed to produce the LCD monitor screen.
However, there may be some dark or bright spots (red, blue, or green) on the screen. This is
not a malfunction. The LCD monitor screen has more than 99.99% effective pixels with a
mere 0.01% of the pixels inactive or always lit. The spots will not be recorded on pictures on
the built-in memory or a card.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TS25 and is the answer not in the manual?

Panasonic Lumix DMC-TS25 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Optical zoom4 x
Focal length range4.5 - 18 mm
Maximum aperture number5.7
Minimum aperture number3.9
Lens structure (elements/groups)11/7
Maximum focal length (35mm film equiv)100 mm
Minimum focal length (35mm film equiv)25 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1300 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3 m
Flash range (wide)0.3 - 4.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1280 x 720 pixels
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Product colorSilver
Scene modesBeach, Children, Night portrait, Panorama, Portrait, Snow, Sports, Underwater
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languagesENG, ESP
Battery life (CIPA standard)250 shots
Number of batteries supported1
Bundled softwarePHOTOfunSTUDIO 9.0 SE / Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth19.7 mm
Width103.7 mm
Height58.3 mm
Weight125 g
Weight (including battery)144 g
