- 21 -
Preparation
• Remove the battery after use. (The battery will be exhausted if left for a long period of time after
being charged.)
• Turn the camera off and wait for the “LUMIX” display on the LCD monitor to clear before removing
the card or battery. (Otherwise, this unit may no longer operate normally and the card itself may be
damaged or the recorded pictures may be lost.)
∫ About the water leakage warning message
To maintain the waterproof performance of this unit, a message prompting to check for any
foreign material inside the side door or to perform maintenance is displayed along with a
warning sound when the following are performed. (P144)
•
When this unit is turned on after opening the side door and replacing the card.
• When this unit is turned on after opening the side door and replacing the battery.
• After opening the side door, close it securely taking care not to get any foreign objects caught.
• If foreign objects are present, wipe them off with a dry, lint-free cloth.
• Warning message display can be turned off by pressing any button.
The AC adaptor (optional) can only be used with the designated
Panasonic DC coupler (optional). The AC adaptor (optional)
cannot be used by itself.
1 Open the side door A.
2 Insert the DC coupler, being careful of the direction.
3 Plug the AC adaptor into an electrical outlet.
4 Connect the AC adaptor B to the [DC IN] socket C of the DC
coupler.
•
Ensure that only the AC adaptor and DC coupler for this camera are
used. Using any other equipment may cause damage.
• Always use a genuine Panasonic AC adaptor (optional).
• When using an AC adaptor, use the AC cable supplied with the AC adaptor.
• Side door cannot be closed while the AC adaptor is connected.
• Do not apply any force to the side door with the weight of the cable or your hand when the AC
adaptor is connected. It may cause damage.
• The DC coupler may get disconnected from this unit if a cable is pulled when connecting the
AC adaptor, so take caution.
• Before removing the DC coupler, turn the camera off and disconnect the AC adaptor.
• Also read the operating instructions for the AC adaptor and DC coupler.
• Waterproof/dustproof function does not operate when the AC adaptor is connected.
Using an AC adaptor (optional) and a DC coupler (optional) instead of the battery

Panasonic Lumix DMC-TS25 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	JPG
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Optical zoom	4 x
Focal length range	4.5 - 18 mm
Maximum aperture number	5.7
Minimum aperture number	3.9
Lens structure (elements/groups)	11/7
Maximum focal length (35mm film equiv)	100 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1300 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3 m
Flash range (wide)	0.3 - 4.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1280 x 720 pixels
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Product color	Silver
Scene modes	Beach, Children, Night portrait, Panorama, Portrait, Snow, Sports, Underwater
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ENG, ESP
Battery life (CIPA standard)	250 shots
Number of batteries supported	1
Bundled software	PHOTOfunSTUDIO 9.0 SE / Adobe Reader

Weight and Dimensions

Depth	19.7 mm
Width	103.7 mm
Height	58.3 mm
Weight	125 g
Weight (including battery)	144 g
