- 57 -
Recording
The available flash range
Shutter speed for each flash setting
¢1 The shutter speed changes depending on the [Stabilizer] setting.
¢2 When [ ] in [Sensitivity] is set.
¢1, 2: The shutter speed becomes a maximum of 1 second in the following cases.
When the Optical Image Stabilizer is set to [OFF].
When the camera has determined that there is very little jitter when the Optical Image Stabilizer is
set to [ON].
In Intelligent Auto Mode, shutter speed changes depending on the identified scene.
The shutter speed for [Sports], [Snow], [Beach & Surf], [Advanced Underwater] and Scene Modes
will be different from above table.
If you bring the Flash too close to an object, the object may be distorted or discolored by the heat or
lighting from the Flash.
Recording a subject from too close, or without sufficient flash will not provide the appropriate level of
exposure, and may result in a picture that is too white or dark.
When the Flash is being charged, the Flash icon blinks red, and you cannot take a picture even
when you press the shutter button fully.
If recording a subject without sufficient flash, the White Balance may not be properly adjusted.
The effects of the flash may not be adequately achieved under the following conditions.
When [Burst] in the [Rec] menu is set to [ ]
When the shutter speed is too fast
It may take time to charge the Flash if you repeat taking a picture. Take a picture after the access
indication disappears.
The Red-Eye Reduction effect differs between people. Also, if the subject is far away from the
camera or was not looking at the first Flash, the effect may not be evident.
Wide Tele
In [ ] in
[Sensitivity]
30 cm (0.98 feet) to 4.4 m (14 feet) 1 m (3.3 feet) to 3 m (9.8 feet)
Flash setting Shutter speed (Sec.) Flash setting Shutter speed (Sec.)
1/60 to 1/1300
1 or 1/8 to 1/1300
¢1
1 or 1/4 to 1/1300
¢2
‰Œ

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TS25 and is the answer not in the manual?

Panasonic Lumix DMC-TS25 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Optical zoom4 x
Focal length range4.5 - 18 mm
Maximum aperture number5.7
Minimum aperture number3.9
Lens structure (elements/groups)11/7
Maximum focal length (35mm film equiv)100 mm
Minimum focal length (35mm film equiv)25 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1300 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3 m
Flash range (wide)0.3 - 4.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1280 x 720 pixels
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Product colorSilver
Scene modesBeach, Children, Night portrait, Panorama, Portrait, Snow, Sports, Underwater
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languagesENG, ESP
Battery life (CIPA standard)250 shots
Number of batteries supported1
Bundled softwarePHOTOfunSTUDIO 9.0 SE / Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth19.7 mm
Width103.7 mm
Height58.3 mm
Weight125 g
Weight (including battery)144 g
