13
Preparation
(ENG) VQT4Z59
∫ Lens
Touch panel of this unit is capacitive. Touch the panel directly with your bare finger.
∫ Touch
To touch and release the touch screen.
Use for selecting items or icons.
•
When selecting features using the touch screen, be sure to
touch the center of the desired icon.
∫ Drag
A movement without releasing the touch screen.
This is used to move the AF area, operate the slide bar,
etc.
This can also be used to move to the next image during
playback, etc.
∫ Pinch (enlarge/reduce)
Pinch the touch panel apart (enlarge) or together
(reduce) with two fingers.
Use to enlarge/reduce the played back images or AF
area.
1 Lens surface
2Tele
3Wide
4 Contact point
5 Lens fitting mark
6 Focus ring
7 Zoom ring
H-FS1442A
Touch screen
2.0X2.0X
2.0X
DMC-G6K&G6P-VQT4Z59_eng.book 13 ページ ２０１３年４月２４日 水曜日 午前１１時２２分
