Panasonic LUMIX S5II User Manual

Wi-Fi / Bluetooth – Wi-Fi Connections
654
[Direct]
Directly connect the camera and the destination device.
Select the method for connecting with the destination device.
[WPS Connection]
[WPS (Push-Button)]: Press the WPS button on the destination device to connect.
• On the camera, press [DISP.] to extend the connection wait time.
[WPS (PIN code)]: Enter the PIN code into the camera, and connect.
[Manual Connection]
Search for the camera on the destination device to connect.
1 Select the network authentication.
[WPA3]/[WPA3/WPA2]
• If [Wi-Fi Password] in [Wi-Fi Setup] is [OFF], this is not displayed if the
connected device is [Smartphone].
2 Enter the SSID and password displayed on the camera into the device.
• If [Wi-Fi Password] in [Wi-Fi Setup] is [OFF], the password is not displayed if
the connected device is [Smartphone].
Select the SSID to establish a connection. (ÎConnecting to a Smartphone
([Wi-Fi connection]): 620)

Panasonic LUMIX S5II Specifications

General

Sensor Type	Full-frame CMOS
Megapixels	24.2 MP
ISO Range	100-51200 (expandable to 50-204800)
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 370 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Image Processor	Venus Engine
Image Stabilization	5-axis in-body stabilization
Autofocus System	Phase Detection AF with 779 points
Video Resolution	6K up to 30p, 4K up to 60p
Viewfinder	OLED Live View Finder (3, 680k-dot)
LCD Screen	3.0-inch free-angle touch screen, 1, 840k-dot
Weight	Approx. 740g (with SD card and battery)
Continuous Shooting	30 fps (electronic shutter)
Storage Media	Dual SD card slots (UHS-II)
Battery	DMW-BLK22 lithium-ion battery
Dimensions	134.3 x 102.3 x 90.1 mm
Weather Sealing	Splash and Dust Resistant
