To Reinstall:
➢ Align the slots on the pre-filter with the
alignment tabs inside dust cup lid
assembly.
➢ Rotate pre-filter clockwise to lock in
place.
➢ Replace the lower portion of the dust
cup by aligning marks as shown,
UNLOCKED (For Cleaning).
➢ Rotate while pressing downward until
marks align as shown; LOCKED (For
Use).
➢ Reinstall the dust cup. (See DUST
CUP, p. 12)
