Warning!
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
•
• Position drain hose properly ,otherwise damage might result in water leakage.
Do not twist,extend the drain hose.
Water
trough
Min.6
0 cm
100 cm
Max
.
Trough
Hose Retainer
Bind
Max.100 cm
Min.60 cm
Min.60 cm
Max.100 cm
If the machine has • drain hose support, please install it like the following .
Warning!
Note!
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
To Next Page
