Panasonic NA-V11FX2

Control Panel
Display
Add Wash lamp:
You can add clothes while lit. (P. 12)
Lock
The door is locked
The door and buttons are
all locked (Child Lock) (P. 26)
Process
Wash
Rinse
Spin
ECONAVI lamp
(P. 18)
Water temperature
Spin speed
: Drain only
(No spin)
Remaining time
Error display (P. 37)
(e.g. U11)
Optional function lamp
 NA-V11FG2/NA-V10FG2
 NA-V90FB1
Auto Tub Care (P. 24)
(P. 24) (P. 23)
(P. 29) (P. 23)
(P. 22) (P. 25)
V90FX2
V11FX2
V10FX2
z Images in these instructions are of the
NA-V11FX2, unless otherwise indicated.
V10FX1
V11FG2 V10FG2
V90FX2V11FX2 V10FX2
V10FX1
8
