23
Replacement of Parts/Specifications
Replacement of Parts
Rubber gasket set
Replace gaskets if they crack, lose their pliancy
or, for any other reasons which allow steam to
escape from between the container and the lid
Mesh filter
Replace the filter, if foreign materials which
clogging the filter cannot be removed, even after
scrubbing with a cleaning brush, etc.
The filter can be
removed by pulling
firmly on it.
Lid cover
Remove gaskets
Consumable parts are available from an
authorized dealer.
Part name Part No.
Rubber gasket set APH65-480
Mesh filter APB97-480-0U
Remove lid, unscrew 3 tapping screws and
remove the lid cover.
Exchange the gaskets and then place the lid
cover back and secure with the tapping screws.
Specifications
Model No. NC-EH40P NC-EH30P NC-EH22P
Power supply 120 V a.c.
Power consumption 700 W
Average power consumption in
keeping warm (approx.)
Amount of water: maximum
Room temperature
: 68ºF (20°C)
at 208 49 Wh 45 Wh 40 Wh
at 190 43 Wh 39 Wh 33 Wh
at 180 35 Wh 31 Wh 27 Wh
at 140 23 Wh 21 Wh 18 Wh
Dimensions
(when the handle is tilted)
Height (approx.)
12.8 in (32.4 cm) 10.8 in (27.5 cm) 9.4 in (23.8 cm)
Width (approx.)
8.5 in (21.7 cm) 8.5 in (21.7 cm) 8.5 in (21.7 cm)
Depth (approx.)
11.3 in (28.7 cm) 11.3 in (28.7 cm) 11.3 in (28.7 cm)
Weight (including power cord) (approx.)
4.6 lb (2.1 kg) 4.4 lb (2.0 kg) 4.2 lb (1.9 kg)
Rated capacity (approx.)
4.2 qt (4.0 L) 3.2 qt (3.0 L) 2.3 qt (2.2 L)
*
Under certain conditions, such as at very hight altitudes and in intense cold, the unit may not function properly.
Please avoid using in such conditions.
*
If the unit is not being used in cold conditions, make sure to empty it of water. The water left in the inner
container may freeze causing damage.
Operating NC-EH40_EN.indd 23 11/7/07 3:58:01 PM
