EN34
Dispenser:
Clean the dispensing spouts weekly or if used intensively, clean it frequently.
Clean the dispenser from the inside and outside with warm water and a suitable
brush to remove any residue and prevent mould from forming.
<Toremove>
1
Presstheleftsideofthedoor
withthedispensertoopen.
(P.EN9)
2
Pressthedispenserupwards.
Pullthedistributionhose
lightlyfromtheinnersideof
thedoorandpressingtothe
leftsothatitclicksoutofthe
fastener.Thenremovethe
dispenser.




<Toattach>
1
Placethedispenserintheupperposition
backintothedoorandpushitslightly
andslideitdownuntiltopofdoorhigh.
2
Pullthehosefrominnersideofthedooropeningandpressitto
therightintotheholderandpushthefunnel-shapedpartofthe
hosebackintothecollaruntilitfitsperfectly.


Holder
Dispenser
Collar Collar
3
Makesuretopofthedooranddispenseraresamehigh,and
closethedoorfirmly.
Cleaning when spout is clogged
1
Disassemblethedispenser.Gripandpulltheloosehoseendneartothe
springandpullbothhoseendswiththesleeveendsoutofthespout.
2
Pullthesleevesoutofhoses

anddisconnectthehosesfromthe
connectingpiece

.Pullthehoseandspringtogetherfromconnecting
piece

.
3
Leavethepartsimmersedinamilksystemcleanerforseveralhours.
Refertotheinstructionsonthemilksystemcleanerfortheexact
quantity.Thenrinsethemthoroughlywithcleanwater.
4
Toassemble,insertbothsleeveendsandhosesbacktogether.Insert
bothsleeveendsintothesmallspouts
1
andpresstheminuntilthey
snapinproperly.Pushtheconnectingpieceintothefixingslot
2
.Then
pushthehosestotherightandleftundertheframe
3
.
Note
• If sleeves are inserted into large spouts, coffee is not dispensed
straight.





 



Correct Incorrect
HowtoClean(Continued)
