Panasonic NE-1064F - Parts List

PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identifi ed by mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specifi ed parts.
!
Ref.
No.
Part No.
Part name &
Description
Pcs/
Set
Remarks
1 F00069660AP CAUTION LABEL 1 APH
1 F00067600CP CAUTION LABEL 1 CPH
2 F00338K00AP FUSE LABEL 1 APH
2 F00338K00CP FUSE LABEL 1 CPH
3 A010T3700BP CERAMIC TRAY 1 1064F APH,1064C CPH
3 A010T8K10AP CERAMIC TRAY 1 1054F APH,1054C CPH,1024F APH,1024C CPH
4 F0903000AG CUSHION RUBBER A 2
5 F0904000BB CUSHION RUBBER A 2
7 F10013700AP BASE 1
8 A1008-1180 RUBBER FOOT 4
9 F110D8K00AP
CABINET BODY（U）
1 1064F APH,1064C CPH
9 F110D8K10AP
CABINET BODY（U）
1 1054F APH,1054C CPH,1024F APH,1024C CPH
10 F11406V00HP STOPPER A 1
11 F10613130AP REAR COVER 1
12 F200A8K00AP OVEN CAVITY 1 1064F APH,1064C CPH
12 F200A8K10AP OVEN CAVITY 1 1054F APH,1054C CPH,1024F APH,1024C CPH
13 F20194210AQ ANTENNA SPACER 2
14 F202K3700BP MOVING ANTENNA 1
15 F20553130AP CEILING COVER 1
16 F30073700BP LOWER HINGE (B) 1
17 J3020-1480 DOOR HOOK 1
18 J3137-1480 HOOK SPACER B 1
19 J3138-1480 HOOK SPACER C 1
20 F4008-1480 FAN BLADE 1
21 F40253700BP AIR GUIDE A 1
22 F41445540AP ORIFICE 1
23 F621B6P10AP H.V.TRANSFORMER 1
24 F03538K00AP
TEMP SENSOR W/LEAD WIRE(U) 1 1064F APH,1064C CPH,1054F APH,1054C CPH
25 F612E5Y30AP INCANDESCENT LAMP (U) 1
26 J6142-1450 MICRO SWITCH 1 (V-16G-3C26-M) PRIMARY LATCH SWITCH
27 J6142-1450 MICRO SWITCH 1
1024F APH,1024C CPH
(V-16G-3C26-M) PRIMARY LATCH SWITCH
27 A61425180AP MICRO SWITCH 1
1054F APH,1054C CPH,1064F APH,1064C CPH
(L-3C2-2) SECONDARY LATCH SWITCH
28 F61448K00AP ANTENNA MOTOR 1
29 F61456N00AP THERMAL CUTOUT 1 FOR OVEN CAVITY
30 F61458K10AP THERMAL CUTOUT 1 FOR MAGNETRON
31 A50966520UP FERRITE CORE 1 CPH
32 ANE6161-3X0 MICRO SWITCH 1 (V-16G-2C25) SHORT SWITCH
33 F60374760GP CAPACITOR HOLDER 1
34 F62025G10XN DIODE,SI 1
35 F62308F20AP FUSE 1 18A
36 F62315G10XN FUSE HOLDER 1 APH
37 XTTBFE4T12A0 SCREW 5 FOR CABINET BODY
38 F60906N60XP H.V.CAPACITOR 1
39 F692Y7600CP NOISE FILTER (U) 1 CPH
40 F900C8K00AP AC CORD W/PLUG 1
!
!
!
!
!
!
!
!
!
!
!
!
