Panasonic NN-SD997S - NN-SN977 S;SN957 S Parts List; NN-SN947 S Parts List

7.6.3. NN-SN977S APH, SN957S APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ310 L0DDEA000014 BUZZER 1 2.0KHz
C10 AECETK1V471B AL CHEM CAPACITOR 1 470µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AAAFD00022 LCD 1
DISP HOLDER F66175W00AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D40,D226,D227 MA2C19600E DIODE 3
D10-D13 B0EAKT000025 DIODE 4
IC1 MN101C54CHY L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D25 D4EAY271A036 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00011 POWER RELAY 1
T10 G4C2AAD00005 LOW VOLTAGE TRANSFORMER 1 120V
VZ340 D3CA6103A017 VARISTOR 1 10KΩ
ΩΩ
Ω
SW1-SW4,SW6-SW8,SW11-SW30 EVQ11L05R SWITCH 27
ZD10 B0BA5R600016 ZENER DIODE 1
7.6.4. NN-SN947S APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ310 L0DDEA000014 BUZZER 1 2.0KHz
C10 AECETK1V471B AL CHEM CAPACITOR 1 470µF/35V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AAAFD00019 LCD 1
DISP HOLDER F66175440XN LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D40,D220,D221,D223 MA2C19600E DIODE 4
D10-D13 B0EAKT000025 DIODE 4
IC1 MN101C54CHY L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D25 D4EAY271A036 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00011 POWER RELAY 1
T10 G4C2AAD00005 LOW VOLTAGE TRANSFORMER 1 120V
VZ340 D3CA6103A017 VARISTOR 1 10KΩ
ΩΩ
Ω
ZD10 B0BA5R600016 ZENER DIODE 1
