Panasonic NV-DA1 - 12.2.2. VTR;Main C.B.A.

Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP06C64A FRONT C.B.A. 1 (RTL)
VEP06C65A REAR OPERATION
C.B.A.
1 (RTL)
VEK8596 MIC UNIT 1 (RTL)
VEP06C84A TOP OPERATION
C.B.A.
1 (RTL)
VEP05352A HEAD AMP C.B.A. 1 (RTL)
12.2.2. VTR/MAIN C.B.A.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP03E59A VTR/MAIN C.B.A. (RTL) NV-DA1EG
/B
VEP03E59B VTR/MAIN C.B.A. (RTL) NV-DA1EN
/ENA
C501
ECUM0J335VBN
C.CAPACITOR CH
6.3V 3.3U
1
C502
ECUM0J335VBN
C.CAPACITOR CH
6.3V 3.3U
1
C503
ECUM0J335VBN
C.CAPACITOR CH
6.3V 3.3U
1
C601 ECST0JX476Z T.CAPACITOR CH
6.3V 47U
1
C602
ECUM1C105KBM
C.CAPACITOR CH
16V 1U
1
C603
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C604
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C605
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C606
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C607
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C608
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C609
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C610
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
47
