Panasonic NV-DA1 - Page 94

Ref. No. Part No. Part Name &
Description
Pcs Remarks
R1158 ERJ2GEJ103 M.RESISTOR CH 1/
16W 10K
1
R1159 ERJ2GEJ473 M.RESISTOR CH 1/
16W 47K
1
R1178 ERJ2GE0R00 M.RESISTOR CH 1/
16W 0
1
R1179 ERJ2GE0R00 M.RESISTOR CH 1/
16W 0
1
R1253 ERJ2GEJ473 M.RESISTOR CH 1/
16W 47K
1
R1254 ERJ2GEJ103 M.RESISTOR CH 1/
16W 10K
1
RA301 EXB28V102J RESISTOR-
RESISTOR
1
RA302 EXB28V102J RESISTOR-
RESISTOR
1
RA311 EXB28V222J RESISTOR-
RESISTOR
1
RA312 EXB28V222J RESISTOR-
RESISTOR
1
RA313 EXB28V222J RESISTOR-
RESISTOR
1
T1001 VTP0499 TRANSFORMER 1
X201 VSX0825 CRYSTAL
OSCILLATOR
1
X301 VSX0947 CERAMIC
OSCILLATOR
1
12.2.8. DRIVE C.B.A.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP02566A DRIVE C.B.A. (RTL)
C2201
ECUX1E273KBV
C.CAPACITOR CH
25V 0.027U
1
C2202
ECUM1A105KBN
C.CAPACITOR CH
10V 1U
1
C2203
ECUX1H270JCQ
C.CAPACITOR CH
50V 27P
1
C2204
ECUM1A564KBN
C.CAPACITOR CH
10V 0.56U
1
C2205
ECUX1E332KBQ
C.CAPACITOR CH
25V 3300P
1
C2207
ECUM1A105KBN
C.CAPACITOR CH
10V 1U
1
C2208
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C2209
ECUX1E223KBV
C.CAPACITOR CH
25V 0.022U
1
C2210
ECUX1C473KBV
C.CAPACITOR CH
16V 0.047U
1
94
