Panasonic NV-DA1 - Page 96

Ref. No. Part No. Part Name &
Description
Pcs Remarks
C2251
ECUX1C103KBQ
C.CAPACITOR CH
16V 0.01U
1
C2255
ECUX1C104ZFQ
C.CAPACITOR CH
16V 0.1U
1
C2256
ECUX1C104ZFQ
C.CAPACITOR CH
16V 0.1U
1
C2257
ECUX1C104ZFQ
C.CAPACITOR CH
16V 0.1U
1
FP2002 VJS3319B022 CONNECTOR
(FEMALE) 22P
1
FP2003 VJS3319B009 CONNECTOR
(FEMALE) 9P
1
FP2004 VJS3320B030 CONNECTOR
(FEMALE) 30P
1
IC2201 TB6519AF IC 1
IC2202 MDC05TR IC 1
IC2203 MDC05TR IC 1
IC2204 TA75S393F IC 1
IC2205 TC75W54FU IC 1
IC2206 TC7S86FU IC 1
IC2207 BA6289F IC 1
PS2001 VJS3989C050 CONNECTOR
(FEMALE) 50P
1
Q2201 2SB1462-R TRANSISTOR 1
Q2202 2SD2216 TRANSISTOR 1
R2201 ERJ2GEJ682 M.RESISTOR CH 1/
16W 6.8K
1
R2202 ERJ2GEJ471 M.RESISTOR CH 1/
16W 470
1
R2204 ERJ2GEJ224 M.RESISTOR CH 1/
16W 220K
1
R2205 ERJ2GEJ102 M.RESISTOR CH 1/
16W 1K
1
R2207 ERJ2GEJ561 M.RESISTOR CH 1/
16W 560
1
R2208 ERJ8GEYJR33 M.RESISTOR CH 1/
8W 0.33
1
R2209 ERJ8GEYJR47 M.RESISTOR CH 1/
8W 0.47
1
R2210 ERJ2GEJ472 M.RESISTOR CH 1/
16W 4.7K
1
R2211 ERJ2GEJ472 M.RESISTOR CH 1/
16W 4.7K
1
R2212 ERJ8RQJR27 M.RESISTOR CH 1/
8W 0.27
1
R2213 ERJ2GEJ471 M.RESISTOR CH 1/
16W 470
1
R2214 ERJ2GEJ102 M.RESISTOR CH 1/
16W 1K
1
R2215 ERJ2GEJ103 M.RESISTOR CH 1/
16W 10K
1
