No. Item / Part Fig. Removal (Screw &
Other)
(8) EVF C.B.A. Fig.6-1 Slide the EVF Slide
Case. / 2-Screws (V) /
Remove the EVF Unit
from Top Case Unit. /
Remove the Wind
Cover. / Remove the
EVF Slide Case.
Fig.6-2 3-Screws (W) / Unhook
----(a) / Unhook----(b)
(9) Camera/VTR
Main C.B.A.
Fig.7-1 1-Screw (X) /
Disconnect PP702/
PS3004. / Remove the
Camera C.B.A. /
Disconnect the
following Connectors.
/ / FP2201, FP2202,
FP2203, FP3201,
PP3002. / 1-Screw (Y) /
Disconnect FP2204. /
Unhook----(c), (d) /
Remove the VTR Main
C.B.A.
Caution for
Connection
of PS3004 &
PP702
Fig.7-2
1. Fixed the position of the
Connector.
2. Insert the Connector.
3. Collation of insertion.
(10) Power C.B.A. Fig.8 1-Screw (Z)
Screw(E) / Remove the
Power C.B.A. from
Battery Case Unit.
(11) Mecha. Unit Fig.9-1 Open the Cassette
Cover (S). / Unlock the
Lock lever for Cover. /
Open the Cassette
Cover (C).
Fig.9-2 3-Screws (A) / 3-
Screws (B) / Remove
the Mecha. Unit.
