No. Item / Part Fig. Removal (Screw &
Other)
(1) Front Case
Unit
Fig.1 Remove the DV Cover
and Grip Belt. / 1-
Screw (A) / 1-Screw (B)
2-Screws (C) / 2-
Screws (D) / Unlock-----
Locking Tab
(2) Mic Unit Fig.2 3-Screws (E) /
Disconnect FP4801.
(3) Side Case
Unit
Fig.3 1-Screw (F) / 7-Screws
(G) / 2-Screws (H) / 1-
Screw (I) / 1-Screw (J)
/ 2-Screws (K) /
Disconnect FP601/
FP602/P4201. /
Remove the Side Case
Unit with LCD Unit.
(4) Top Case Unit Fig.3 Disconnect FP6002/
FP603. / Remove the
Top Case Unit.
(5) LCD Unit Fig.4-1 Open the LCD Panel
as Fig. 4-1. / 2 Screws
(L)
Fig.4-2 Remove the LCD Unit
from Side Case Unit. /
3-Screws (M) / 2-
Screws (N) / 1-Screw
(O)
Fig.4-3 1-Screw (P) / 1-Screw
(Q)
(6) Lens Unit Fig.5 2-Screws (R) /
Disconnect PP202/
FP701. / Remove the
Lens Unit.
(7) Battery Case
Unit
Fig.5 2-Screws (S) / 1-Screw
(T) / 1-Screw (U) /
Disconnect FP1002/
PS1001/PS1002. /
Remove the Battery
Case Unit.
