For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : consumerproducts@panasonic.com
Cassette Information
1 Turn Tape Wheel in direction of arrow
until there is no slack.
2 Attach Battery (page 8).
3 Slide TAPE EJECT to open door.
4 Insert cassette as shown.
5 Press here to close door.
1
2
3
4
• To remove the cassette, slide the TAPE
EJECT switch.
5
1 To prevent accidental erasing,
break off tab with screwdriver.
(Or, slide tab open.)
2 To record again,
cover hole with adhesive tape.
(Or, slide tab closed.)
Protects tapes from being accidentally
erased.
Erase Protection Tab
Cassette Insertion/Removal
Slide tab type
12
• SLP playback may contain more picture noise.
SLP
(Super Long Play)
SP
(Standard Play)
Cassette type
Tape Speed
Selector Position
TC-20
20 minutes
1 hour
30 minutes
TC-30 TC-40
40 minutes
1 hour
30 minutes
2 hours
Use tapes with the mark in this unit.
Record/Playback Time
