▶ LCD Type
15˝ Diagonal AM-TFT(Active-Matrix)
Pixel pitch (mm) : 0.297(H) 0.297(V)
BRIGHTNESS: 250cd/㎡(Typical)
CONTRAST RATIO:600:1(Typical)
RESPONSE TIME: 8msec (Typical)
▶ RESOLUTION(H x V)
1024X768 @ 60Hz
▶ FREQUENCY
HORIZONTAL : 31KHz - 48KHz
VERTICAL : 56Hz - 75Hz
▶ INPUT SIGNAL
RGB (Analog 0.7Vp-p / 75Ω)
SYNC(Separate TTL Level)
AV(2ch input 1.0Vp-p, 75Ω terminated, loop-through out)
S-VIDEO(1ch input (Y/C) , loop-through out),
AV(composite,S-VIDEO) Sound L/R
PC Stereo Sound
▶ ACTIVE DISPLAY AREA (W x H)
304.1mm X 228.1mm
▶ PACKING DIMENSIONS (W x D x H)
435mm X472mm X 233mm
▶ WEIGHT
Net Weight : 3.7Kg
Gross Weight : 5.7Kg
▶ ELECTRICAL RATINGS
DC 12V/3A
▶ NOTE :
Technical specifications are subject to change without notice.
