Panasonic PV-20DF25 - Page 78

Ref.
No.
Part No. Part Name & Description Remarks
R5616 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R5618 ERJ3GEYJ273V MGF CHIP 1/16W 27K
R5619 ERJ3GEYJ563V MGF CHIP 1/16W 56K
R5621 ERJ3GEYJ182V MGF CHIP 1/16W 1.8K
R5622 ERJ3GEYJ471V MGF CHIP 1/16W 470
R5651 ERJ3GEYJ331V MGF CHIP 1/16W 330
R5652 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R5653 ERJ3GEYJ682V MGF CHIP 1/16W 6.8K
R5655 ERJ3GEYJ821V MGF CHIP 1/16W 820
R5656 ERJ3GEYJ153V MGF CHIP 1/16W 15K
R5657 ERJ3GEYJ333V MGF CHIP 1/16W 33K
R5658 ERJ3GEYJ122V MGF CHIP 1/16W 1.2K
R5659 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R5660 ERJ3GEYJ821V MGF CHIP 1/16W 820
R5661 ERJ3GEYJ101V MGF CHIP 1/16W 100
R5662 ERJ3GEYJ101V MGF CHIP 1/16W 100
R5664 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R5665 ERJ3GEYJ562V MGF CHIP 1/16W 5.6K
R5666 ERJ3GEYJ392V MGF CHIP 1/16W 3.9K
R5673 ERJ3GEYJ392V MGF CHIP 1/16W 3.9K
R5674 ERJ3GEYJ272V MGF CHIP 1/16W 2.7K
R5676 ERJ3GEYJ272V MGF CHIP 1/16W 2.7K
R5902 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R5932 ERJ3GEYJ101V MGF CHIP 1/16W 100
R5933 ERJ3GEYJ101V MGF CHIP 1/16W 100
R6005 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6006 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6012 ERJ3GEYJ101V MGF CHIP 1/16W 100
R6014 ERJ3GEY0R00V MGF CHIP 1/16W 0
R6017 ERJ3GEYJ471V MGF CHIP 1/16W 470
R6025 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6026 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6027 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6028 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6029 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6034 ERJ3GEYJ332V MGF CHIP 1/16W 3.3K
R6035 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6036 ERJ3GEYJ223V MGF CHIP 1/16W 22K
R6039 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6041 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6042 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6043 ERJ3GEYJ223V MGF CHIP 1/16W 22K
R6047 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6048 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6051 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6054 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6056 ERJ3GEYJ471V MGF CHIP 1/16W 470
R6058 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6059 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6060 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6062 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6063 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6064 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6065 ERJ3GEYJ561V MGF CHIP 1/16W 560
R6066 ERJ3GEYJ561V MGF CHIP 1/16W 560
R6067 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6068 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6069 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6070 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6071 ERJ3GEY0R00V MGF CHIP 1/16W 0
R6072 ERJ3GEYJ101V MGF CHIP 1/16W 100
R6078 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6079 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6080 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6081 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6085 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6086 ERJ3GEYJ105V MGF CHIP 1/16W 1M
R6089 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6090 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R6093 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6095 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6112 ERJ3GEYJ223V MGF CHIP 1/16W 22K
R6113 ERJ3GEYJ183V MGF CHIP 1/16W 18K
Ref.
No.
Part No. Part Name & Description Remarks
R6114 ERJ6GEYJ391V MGF CHIP 1/10W 390
R6115 ERJ3GEYJ103V MGF CHIP 1/16W 10K
R6117 ERDS2TJ560T CARBON 1/4W 56
R6118 ERJ3GEYJ475V MGF CHIP 1/16W 4.7M
R6119 ERJ3GEYJ332V MGF CHIP 1/16W 3.3K
R6120 ERJ3GEYJ152V MGF CHIP 1/16W 1.5K
R6121 ERJ3GEYJ221V MGF CHIP 1/16W 220
R6122 ERJ3GEYJ221V MGF CHIP 1/16W 220
R6123 ERJ3GEYJ473V MGF CHIP 1/16W 47K
R6129 ERJ3GEYJ223V MGF CHIP 1/16W 22K
R6130 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6175 ERJ3GEYJ473V MGF CHIP 1/16W 47K
R6301 ERJ3EKF2201V MGF CHIP 1/16W 2.2
R6302 ERJ3EKF3301V MGF CHIP 1/16W 3.3K
R6303 ERJ3EKF5601V MGF CHIP 1/16W 5.6K
R6306 ERJ3EKF2201V MGF CHIP 1/16W 2.2
R6307 ERJ3EKF3301V MGF CHIP 1/16W 3.3K
R6311 ERJ3EKF2201V MGF CHIP 1/16W 2.2
R6312 ERJ3EKF3301V MGF CHIP 1/16W 3.3K
R6313 ERJ3EKF5601V MGF CHIP 1/16W 5.6K
R6316 ERJ3EKF1102V MGF CHIP 1/16W 11K
R6317 ERJ3EKF1102V MGF CHIP 1/16W 11K
R6318 ERJ3EKF1102V MGF CHIP 1/16W 11K
R6401 ERJ3GEYJ105V MGF CHIP 1/16W 1M
R6511 ERJ3GEYJ472V MGF CHIP 1/16W 4.7K
R6512 ERJ3GEYJ472V MGF CHIP 1/16W 4.7K
R6513 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6514 ERJ3GEYJ472V MGF CHIP 1/16W 4.7K
R6515 ERJ3GEYJ222V MGF CHIP 1/16W 2.2K
R6516 ERJ3GEYJ101V MGF CHIP 1/16W 100
R6517 ERJ3GEYJ223V MGF CHIP 1/16W 22K
R6518 ERJ3GEYJ562V MGF CHIP 1/16W 5.6K
R6522 ERJ3GEY0R00V MGF CHIP 1/16W 0
R7001 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R7002 ERJ3GEYJ101V MGF CHIP 1/16W 100
R7003 ERJ3GEYJ101V MGF CHIP 1/16W 100
R9002 ERJ3GEYJ101V MGF CHIP 1/16W 100
R9003 ERJ3GEYJ101V MGF CHIP 1/16W 100
R9004 ERJ3GEYJ332V MGF CHIP 1/16W 3.3K
R9005 ERJ3GEYJ473V MGF CHIP 1/16W 47K
R9006 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R9007 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R9008 ERJ3GEYJ473V MGF CHIP 1/16W 47K
R9501 ERJ3GEYJ750V MGF CHIP 1/16W 75
R9502 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R9503 ERJ3GEYJ102V MGF CHIP 1/16W 1K
R9509 ERJ3GEYJ221V MGF CHIP 1/16W 220
R9510 ERJ3GEYJ221V MGF CHIP 1/16W 220
Z6203 ERDS2T0T CARBON 1/4W 0
CAPACITORS
Ref.
No.
Part No. Part Name & Description Remarks
C801 F0CAF334A021 POLYESTER 125V 0.33UF
C803 F0CAF104A021 POLYESTER 125V 0.1UF
C804 ECKATS102ME CERAMIC 250V 1000PF
or C804 ECKETS102ME CERAMIC 250V 1000PF
or C804 F1BAF102A059 CERAMIC 250V 1000PF
or C804 F1BAH1020011 CERAMIC 250V 1000PF
or C804 F1BAH1020013 CERAMIC 250V 1000PF
or C804 F1B2E1020004 CERAMIC 250V 1000PF
C806 F1BAF472A082 CERAMIC 250V 4700PF
C807 F1BAF472A082 CERAMIC 250V 4700PF
C808 F1BAF472A082 CERAMIC 250V 4700PF
C809 F1BAF472A082 CERAMIC 250V 4700PF
C855 ECA1HHG470B ELECTROLYTIC 50V 47UF
C856 ECJ1VB1H471K C CHIP 50V 470PF
C857 F2B2D3310020 ELECTROLYTIC 200V 330UF ( A,B
)
C857 ECEC2DP561BB ELECTROLYTIC 200V 560UF (
C,D,E )
C858 F1B3D152A010 CERAMIC 2KV 1500PF
C859 F1H1H221A009 C CHIP 50V 220PF
C861 ECKATS152ME CERAMIC 250V 1500PF
78
PV-20DF25 / PV-27DF25 / PV-27DF5 / PV-20DF25-K / PV-27DF25-K
