Ref.
No.
Part No. Part Name & Description Remarks
SW6307 EVQ21405R SWITCH PUSH
SW6308 EVQ21405R SWITCH PUSH
SW6309 EVQ21405R SWITCH PUSH
SW6318 EVQ21405R SWITCH PUSH
FUSE & PROTECTOR
Ref.
No.
Part No. Part Name & Description Remarks
F801 K5D632AQ0002 FUSE 125V 6.3A
or F801 K5D632ADA001 FUSE 125V 6.3A
PR850 D4FA7R00A002 IC PROTECTOR 7A
RELAY
Ref.
No.
Part No. Part Name & Description Remarks
RL591 LSSY0004 RELAY
RL801 K6B1AGA00177 RELAY
or
RL801
K6B1AGA00037 RELAY
or
RL801
K6B1AGA00042 RELAY
TRANSFORMER
Ref.
No.
Part No. Part Name & Description Remarks
T850 ETS35AA6S5ND TRANSFORMER
T1001 LSTP0129 TRANSFORMER SWITCHING
JACKS
Ref.
No.
Part No. Part Name & Description Remarks
JK1601 B3RAE0000030 IC, JACK OPTICAL OUTPUT
JK4591 K2HC103B0047 EARPHONE JACK SOCKET
JK4701 K2HA306B0094 FRONT AUDIO/VIDEO JACK SOCKET
JK9501 K2HA203B0014 AUDIO JACK SOCKET
JK9502 K2HA305B0004 AUDIO/VIDEO JACK SOCKET
MISCELLANEOUS
Ref.
No.
Part No. Part Name & Description Remarks
483 XYN3+F10FJ SCREW W/WASHER,STEEL
487 XYN3+J8FJ SCREW W/WASHER,STEEL
712 VMTS0035 CUSHION,RUBBER
716 LSMF0389 SHEET
743 J3AAABB00002 TUNER,UHF/VHF NR
771 EYF52BCY FUSE HOLDER
797 LSSC0529 HEAT SINK ( A,B )
797 LSSC0562 HEAT SINK ( C,D,E )
799 LSSC0793 HEAT SINK
12.3.2. OPERATION C.B.A.
DIODES
Ref.
No.
Part No. Part Name & Description Remarks
D6304 B3ACA0000192 LIGHT EMITTING DIODE ORANGE
CAPACITORS
Ref.
No.
Part No. Part Name & Description Remarks
C6303 ECQB1H104KF POLYESTER 50V 0.1UF
PIN HEADERS
Ref.
No.
Part No. Part Name & Description Remarks
P6302 LSJWD7S040AA CONNECTOR CABLE W/OUT PLUG
SWITCHES
Ref.
No.
Part No. Part Name & Description Remarks
SW6304 EVQ21405R SWITCH PUSH
SW6316 EVQ21405R SWITCH PUSH
SW6317 EVQ21405R SWITCH PUSH
MISCELLANEOUS
Ref.
No.
Part No. Part Name & Description Remarks
711 PNA4611M00HC INFRARED RECEIVER UNIT
12.3.3. DEFLECTION C.B.A.
INTEGRATED CIRCUITS
Ref.
No.
Part No. Part Name & Description Remarks
IC451 C1AA00000709 IC, LINEAR
IC752 C0ABAA000005 IC, LINEAR ( C,D,E )
TRANSISTORS
Ref.
No.
Part No. Part Name & Description Remarks
Q431 2SA1309AHA TRANSISTOR SI PNP CHIP
or Q431 B1ACCF000047 TRANSISTOR SI PNP CHIP
Q501 B1AACN000015 TRANSISTOR SI NPN ( A,B )
Q501 2SC3941H TRANSISTOR SI NPN ( C,D,E )
Q523 2SA17670QA TRANSISTOR SI PNP CHIP
Q551 B1BAFT000005 TRANSISTOR SI NPN ( A,B )
Q551 B1BAES000002 TRANSISTOR SI NPN ( C,D,E )
Q571 2SD1819A0L TRANSISTOR SI NPN CHIP
or Q571 B1ABCF000020 TRANSISTOR SI NPN CHIP
Q751 2SD14990P0LB TRANSISTOR SI NPN ( C,D,E )
Q753 2SA1309AHA TRANSISTOR SI PNP CHIP (
C,D,E )
or Q753 B1ACCF000047 TRANSISTOR SI PNP CHIP (
C,D,E )
Q754 2SC3311A0A TRANSISTOR SI NPN ( C,D,E )
or Q754 B1AACF000092 TRANSISTOR SI NPN ( C,D,E )
or Q754 B1AACF000095 TRANSISTOR SI NPN ( C,D,E )
DIODES
Ref.
No.
Part No. Part Name & Description Remarks
D401 B0AAML000001 DIODE SI
or D401 B0EAKL000008 DIODE SI
D402 MA2C165001VT DIODE SI
or D402 B0AACK000004 DIODE SI
D503 B0HAGP000014 DIODE SI
D504 MAZ40470MF DIODE ZENER 4.7V
or D504 B0BA4R600003 DIODE ZENER 4.7V
D505 MA2C165001VT DIODE SI
or D505 B0AACK000004 DIODE SI
D506 MAZ42700MF DIODE ZENER 27V ( C,D,E )
D553 B0HAGP000014 DIODE SI
D554 MA2C16700E DIODE SI
or D554 B0AAEL000001 DIODE SI
D555 MAZ40680MF DIODE ZENER 6.8V
or D555 B0BA6R600008 DIODE ZENER 6.8V
D558 B0HAGP000014 DIODE SI
D571 B0HANV000017 DIODE SI ( C,D,E )
or D571 B0HAMV000028 DIODE SI ( C,D,E )
D572 B0HAMR000076 DIODE SI ( C,D,E )
or D572 B0HAMR000060 DIODE SI ( C,D,E )
or D572 B0HAMR000063 DIODE SI ( C,D,E )
D704 MA2C029TAF DIODE SI ( C,D,E )
D752 MA2C165001VT DIODE SI ( C,D,E )
or D752 B0AACK000004 DIODE SI ( C,D,E )
RESISTORS
Ref.
No.
Part No. Part Name & Description Remarks
R401 ERJ3GEYJ471V MGF CHIP 1/16W 470 ( A,B )
R401 ERJ3GEYJ122V MGF CHIP 1/16W 1.2K ( C,D,E )
R402 ERDS2TJ223 CARBON 1/4W 22K ( A,B )
81
PV-20DF25 / PV-27DF25 / PV-27DF5 / PV-20DF25-K / PV-27DF25-K
