Panasonic RF-562DGU

9.2. Component Part list
Ref. No. Part No. Part Name & Description Remarks
P.C.B
RUP4N044XB-2 Main P.C.B. (GC) / Battery P.C.B. (GC) [M]
RUP4N044XA-7 Main P.C.B. (GU) / Battery P.C.B. (GU) [M]
INTEGRATED CIRCUITS
IC1 TA7358P IC (FRONT END) [M]
IC2 AN7236 IC [M]
TRANSISTORS
Q1 2SC829BTA TRANSISTOR [M]
Q101 KTC3199LGRAT TRANSISTOR [M]
Q102 KTC3199LGRAT TRANSISTOR [M]
Q103 KTC3203YAT TRANSISTOR [M]
Q104 KTC3203YAT TRANSISTOR [M]
DIODES
D101 MA27B1TA DIODE [M]
VARIABLE RESISTORS
VR1 RRVN16G4A14P VARIABLE RESISTOR [M]
SWITCHES
SW1 RSS3F09ZA-B BAND SWITCH [M]
TRIMMER
CT1 RCV4RC2V2K-M VARIABLE CAPASITOR [M]
CT2 RCV4RC2V2K-M CARIABLE CAPACITOR [M]
CT3 RCV4RC2V2K-M CARIABLE CAPACITOR [M]
CT4 RCV4RC2V2K-M VARIABLE CAPASITOR [M]
CT5 RCVTZ11F TRIMMER CAPACITOR [M]
CT6 RCV05AF2-S TRIMMER CAPACITOR [M]
COILS & TRANSFORMERS
L2 RLD4Y53W FM OSC COIL [M]GU1
L2 RL04P004 FM OSC COIL [M]GC1
L3 RLVN5E02-0Z FERRITE ANTENNA [M]
L4 RLVN5E02-0Z FERRITE ANTENNA [M]
L5 RLQY30S1W RF CHOKE COIL [M]
L7 RLQY75S5 CHOKE COIL [M]
L8 RL02B108 AM OSC COIL [M]
L9 RL03B46 SW OSC COIL [M]
