Panasonic RG-C811A - Wiring Diagrams and Selector Indication; Wiring Diagrams; Selector Indication

RG-C811HA
5
RG-C811A
RG-C811HA
DIMENSIONS (CONTINUED)
WIRING DIAGRAM
SELECTOR INDICATION (RG-C811HA only)
AC 120 V 60 Hz
(Power supply)
Fan body
Main control circuit
DC
Motor
Main control
circuit
(Ground wire)
Green
Junction box
Neutral
White
Black Live (Fan)
AC 120 V 60 Hz
(Power supply)
Junction box
Neutral
White
Black Live (Fan)
(Ground wire)
Green
DC
Motor
Fan body
Main control circuit
Main control
circuit
Humidity sensor
Selector
TimerHumidity
setting
Humidity
preset selector
Timer
preset selector
Selector indications on
blower unit
Factory setting is around 50%.
Timer preset selector positions
13 (330)
10 1/4 (261)
3 7/8
(100)
Part name
Part nameNo.
No.
Blade
Grille
Junction box
Adaptor
PCB box
Pick-A-Flow™ switch
Fan body
Damper
Flex-Z Fast™ bracket
Selector
Humidity sensor
