Names of Parts
INDOOR UNIT
OUTDOOR UNIT
Label
(attached to the lid of electrical component box)
This air conditioner incorporates a biocidal product.
Ionized air generated by a device incorporated
in the air conditioner deactivates bacteria and
viruses in the air, and on surfaces, and inhibits
mould growth on surfaces.
Active substances: free radicals generated in situ
from ambient air or water
PZH3
(Type 36, 50, 60)
PZH2
(Type 36, 50, 60)
PZH3
(Type 71)
PZH2
(Type 71)
PZH3
(Type 100, 125, 140)
PZH2
(Type 100, 125, 140)

Operation&AdjustingAirflowDirection
Refer to the Operating Instructions attached to the Remote Controller.
A
Model No.
CZ-RTC4
For all indoor
units
Read the Operating Instructions included with the Remote Controller.
Wireless Remote
Controller
Timer Remote
Controller
Wired Remote
Controller
High-spec Wired
Remote Controller
Optional
Air intake
Air outlet
Air intake
Air intake
Air outlet
Air outlet
PZ3
(Type 36, 50)
PZ2
(Type 60, 71)
PZ3
(Type 100, 125, 140)
PZ2
(Type 100, 125, 140)
PZ3
(Type 60, 71)
Air intake
Air outlet
Air outlet
Air outlet
Air intake
Air intake
Air intake
Air outlet
Model No. CZ-RWS3
The receiver : Model No.
CZ-RWRC3
(For all indoor units)
(Infrared Remote Controller)
Model No.
CZ-RTC5B
For all indoor
units
Model No.
CZ-RTC6
series
For all indoor
units
Type F3
(Middle Static Pressure Duct)
Air outlet duct *
Suspension bolt *
Ceiling material *
Indoor unit
Air outlet grille *
* Field supplied
At standard installation
(Horizontal installation in the ceiling, rear side air intake)
