SPECIFICATIONS
 Mini (LE1 type) (Single-phase)
Model Name U-4LE1H4(E) U-5LE1H4(E) U-6LE1H4(E)
Power Source 220 - 230 - 240 V, single-phase, 50 Hz
Cooling capacity
kW 12.1 14.0 15.5
BTU / h 41,300 47,800 52,900
Heating capacity
kW 12.5 16.0 18.0
BTU / h 42,700 54,600 61,400
Sound Pressure
level (C/H)
dB(A) 50/52 51/53 52/55
Sound Power level
(C/H)
dB(A) 68/70 69/71 70/73
Unit Dimensions
(H×W×D)
mm 1330×940×340
Net weight kg 104 104 104
 Mini (LE1 type) (3-phase)
Model Name U-4LE1H7(E) U-5LE1H7(E) U-6LE1H7(E)
Power Source 300 - 400 - 415 V, 3-phase, 50 Hz
Cooling capacity
kW 12.1 14.0 15.5
BTU / h 41,300 47,800 52,900
Heating capacity
kW 12.5 16.0 18.0
BTU / h 42,700 54,600 61,400
Sound Pressure
level (C/H)
dB(A) 50/52 51/53 52/55
Sound Power level
(C/H)
dB(A) 68/70 69/71 70/73
Unit Dimensions
(H×W×D)
mm 1330×940×340
Net weight kg 103 103 103
