Panasonic S-36MK2E5A

7
ENGLISH
OPERATION
Names of Parts
INDOOR UNIT
OPEN
CLOS
E
CLOS
E
OPEN
Airfl ow direction
louver
Intake grille
Air is discharged
evenly
Control Panel
Receiver
Emergency button
Y2 type (4-WAY CASSETTE 60×60)
Front panel
Air Filters
Vertical airfl ow
direction louver
• Do not adjust
by hand.
Horizontal airfl ow
direction louver
• Manually
adjustable.
Receiver
Emergency button
K2 type (WALL MOUNTED)
Wireless Remote Controller (Optional parts)
NOTE
Refer to the Operating Instructions attached to the
optional Wireless Remote Controller.
(Wireless type: available
for all indoor units)
High-Spec Wired Remote Controller (Optional parts)
NOTE
Refer to the Operating Instructions attached to the
optional High-Spec Wired Remote Controller.
(Wired type: available for
all indoor units)
