Panasonic S-36PN1E5

1
1-425
Optional Duct Frange
1. Remove the air outlet duct frange.
How to Install Duct Frange
2. Attach the duct frange to the side of the unit with the supplied screws.
Duct frange
4 circle duct frange (CZ-160DAF2)
3 circle duct frange (CZ-90DAF2)
2 circle duct frange (CZ-56DAF2)
