Panasonic S-36PU1E5A

1
1-440
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 43°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-36PY2E5A×2
U-71PEY1E5
220V
230V
240V
50Hz
1phase
23
16 7.9 5.7 2.34 7.5 5.5 2.56 7.2 5.4 2.78 6.1 4.6 2.45 5.5 4.2 2.23
19 8.5 4.4 2.44 8.1 4.2 2.67 7.7 4.1 2.90 6.5 3.5 2.55 5.9 3.2 2.32
22 9.2 3.2 2.53 8.8 3.0 2.77 8.4 2.8 3.02 7.1 2.5 2.65 6.4 2.2 2.42
25
16 7.9 6.5 2.34 7.5 6.2 2.56 7.2 6.0 2.78 6.1 5.2 2.45 5.5 4.9 2.23
19 8.5 5.2 2.44 8.1 5.0 2.67 7.7 4.8 2.90 6.5 4.2 2.55 5.9 3.9 2.32
22 9.2 3.9 2.53 8.8 3.8 2.77 8.4 3.6 3.02 7.1 3.1 2.65 6.4 2.8 2.42
27
16 7.9 7.2 2.34 7.5 7.0 2.56 7.2 6.8 2.78 6.1 5.9 2.45 5.5 5.4 2.23
19 8.5 6.0 2.44 8.1 5.8 2.67 7.7 5.5 2.90 6.5 4.9 2.55 5.9 4.5 2.32
22 9.2 4.7 2.53 8.8 4.6 2.77 8.4 4.4 3.02 7.1 3.8 2.65 6.4 3.5 2.42
29
16 7.9 7.9 2.34 7.5 7.5 2.56 7.2 7.2 2.78 6.1 6.1 2.45 5.5 5.5 2.23
19 8.5 6.8 2.44 8.1 6.5 2.67 7.7 6.3 2.90 6.5 5.4 2.55 5.9 5.2 2.32
22 9.2 5.5 2.53 8.8 5.4 2.77 8.4 5.2 3.02 7.1 4.5 2.65 6.4 4.2 2.42
32
16 7.9 7.9 2.34 7.5 7.5 2.56 7.2 7.2 2.78 6.1 6.1 2.45 5.5 5.5 2.23
19 8.5 6.8 2.44 8.1 6.5 2.67 7.7 6.3 2.90 6.5 5.4 2.55 5.9 5.2 2.32
22 9.2 5.5 2.53 8.8 5.4 2.77 8.4 5.2 3.02 7.1 4.5 2.65 6.4 4.2 2.42
S-50PY2E5A×2
U-100PEY1E5
(U-100PEY1E8)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 10.6 7.7 3.44 10.1 7.3 3.70 9.6 7.0 3.97 8.2 6.3 3.77 5.9 4.8 2.60
19 11.4 6.0 3.59 10.8 5.7 3.86 10.3 5.5 4.14 8.7 4.7 3.93 6.3 3.6 2.71
22 12.4 4.3 3.71 11.9 4.1 4.00 11.3 3.9 4.28 9.6 3.2 4.07 6.9 2.3 2.81
25
16 11.0 9.1 3.49 10.5 8.7 3.77 10.0 8.3 4.04 8.5 7.4 3.84 6.1 5.7 2.64
19 11.8 7.3 3.65 11.2 6.9 3.93 10.6 6.6 4.21 9.0 5.8 4.00 6.5 4.4 2.76
22 12.9 5.5 3.77 12.3 5.3 4.06 11.7 5.0 4.36 9.9 4.4 4.14 7.1 3.2 2.85
27
16 11.4 10.5 3.55 10.8 10.0 3.83 10.3 9.5 4.10 8.7 8.6 3.90 6.3 6.3 2.69
19 12.2 8.7 3.71 11.6 8.3 3.99 11.0 7.9 4.28 9.3 7.0 4.07 6.7 5.4 2.80
22 13.3 7.0 3.83 12.7 6.6 4.13 12.1 6.3 4.43 10.2 5.5 4.21 7.3 4.1 2.90
29
16 11.5 11.5 3.56 11.0 11.0 3.84 10.5 10.5 4.11 8.9 8.9 3.91 6.4 6.4 2.69
19 12.3 9.9 3.72 11.7 9.4 4.00 11.2 9.1 4.29 9.5 8.1 4.08 6.8 6.3 2.81
22 13.5 8.2 3.84 12.9 7.8 4.14 12.2 7.4 4.44 10.4 6.6 4.22 7.5 5.1 2.91
32
16 11.7 11.7 3.57 11.2 11.2 3.85 10.6 10.6 4.12 9.0 9.0 3.92 6.5 6.5 2.70
19 12.5 10.0 3.72 11.9 9.6 4.01 11.3 9.2 4.30 9.6 8.2 4.09 6.9 6.4 2.82
22 13.7 8.3 3.85 13.1 8.0 4.15 12.4 7.6 4.45 10.5 6.6 4.23 7.6 5.2 2.91
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Multiple Unit
4-Way Cassette 60×60 Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
