Panasonic S-36PU1E5A

5-14
5
•
•
Regarding the remote controller check, refer to the Reference Materials.
For information on the procedures for replacing the nonvolatile memory (EEPROM) of the indoor unit and/or replacing the
indoor unit’s control board, refer to the manual that is packaged with the indoor unit service board.
TERMINAL EEPROM
TERMINAL EEPROM
Outdoor Unit Control PCB
A747898 : (U-60PE1E5A, U-71PE1E5A)
(for single-phase outdoor unit PCB)
CR-50PE1E5 : Up side (U-50PE1E5)
(for single-phase outdoor unit PCB)
EEPROMTERMINAL
A747895 : (U-100PE1E5A)
(for single-phase outdoor unit PCB)
A747896 : (U-125PE1E5A, U-140PE1E5A)
(for single-phase outdoor unit PCB)
TERMINAL
EEPROM
