Panasonic SA-NS55E - Page 81

Ref.
No.
Part No. Part Name & Description Remarks
CN801 K1MN06A00013 6P FFC CONNECTOR [M]
CN802 K1MN22AA0004 22P FFC CONNECTOR [M]
CN803 K1KA12AA0319 12P CONNECTOR [M]
CN803A K1KA09AA0193 9P CONNECTOR [M]
CN805 K1KA12AA0319 12P CONNECTOR [M]
CN806A K1MN13BA0147 13P CONNECTOR [M]
CN806B K1KZ13A00001 13P CONNECTOR [M]
CN807 K1MN22AA0004 22P CONNECTOR [M]
CN808 K1KA02AA0193 2P CONNECTOR [M]
CN810 K1KA09AA0193 9P CONNECTOR [M]
CN901A K1MN14B00024 14P CONNECTOR [M]
CN901B K1MN14A00090 14P CONNECTOR [M]
CN2401 K1FY124DA001 CONNECTOR (IPOD) [M]
CN7001 K1MN16B00154 16P FFC CONNECTOR [M]
CN7002 K1MN22BA0005 22P CONNECTOR [M]
P901 K1MN22BA0005 22P CONNECTOR [M]
P903 K1FY104B0011 CONNECTOR (USB) [M]
COILS & T RANSFORMERS
L270 G0AR76Y00003 CHOKE COIL [M]
L271 G0AR76Y00003 CHOKE COIL [M]
L470 G0AR76Y00003 CHOKE COIL [M]
L471 G0AR76Y00003 CHOKE COIL [M]
L500 G0B371HA0005 LINE FILTER [M]
L801 J0JKB0000020 EMI BEAD CORE [M]
L812 J0JKB0000020 EMI BEAD CORE [M]
L850 G0C3R3JA0027 COIL [M]
L851 G0C3R3JA0027 COIL [M]
L900 G1C100K00019 CHIP COIL [M]
L901 G0C3R3JA0027 COIL [M]
L920 J0JKB0000020 EMI BEAD CORE [M]
L921 J0JKB0000020 EMI BEAD CORE [M]
LB700 J0JBC0000015 CHIP INDUCTOR [M]
LB701 J0JBC0000015 CHIP INDUCTOR [M]
LB840 J0JAC0000021 CHIP INDUCTOR [M]
LB841 J0JAC0000021 CHIP INDUCTOR [M]
LB843 J0JAC0000021 CHIP INDUCTOR [M]
LB845 J0JAC0000021 CHIP INDUCTOR [M]
LB846 J0JAC0000021 CHIP INDUCTOR [M]
LB848 J0JAC0000021 CHIP INDUCTOR [M]
LB850 J0JHC0000045 CHIP INDUCTOR [M]
LB852 J0JHC0000045 CHIP INDUCTOR [M]
LB930 J0JHC0000045 CHIP INDUCTOR [M]
LB932 J0JAC0000021 CHIP INDUCTOR [M]
LB933 J0JAC0000021 CHIP INDUCTOR [M]
LB934 J0JAC0000021 CHIP INDUCTOR [M]
LB935 J0JAC0000021 CHIP INDUCTOR [M]
LB936 J0JAC0000021 CHIP INDUCTOR [M]
LB938 J0JAC0000021 CHIP INDUCTOR [M]
LB951 J0JHC0000045 CHIP INDUCTOR [M]
LB952 J0JHC0000045 CHIP INDUCTOR [M]
LB7262 D0GBR00JA008 CHIP JUMPER [M]
LB7263 D0GBR00JA008 CHIP JUMPER [M]
LB7264 D0GBR00JA008 CHIP JUMPER [M]
T501 G4CYAYY00148 TRANSFORMER [M]
T502 G4CYAYY00137 SUB TRANSFORMER [M]
COMPONENT COMBINATION
Z500 ERZV10V511CS ZENER [M]
Z800 ENG07823QF TUNER PACK [M]
Z901 B3RAD0000152 IR SENSOR [M]
ZJ400 SNE1004-3 EARTH TERMINAL [M]
RELAY
RL501 K6B1AEA00015 POWER RELAY [M]
Ref.
No.
Part No. Part Name & Description Remarks
OSCILLATORS
X320 H0H433400002 CRYSTAL OSCILLATOR [M]
X801 H4Z8004AA001 CERAMIC RESONATOR [M]
X802 H0A327200100 CRYSTAL OSCILLATOR [M]
X900 H0D120500009 CRYSTAL OSCILLATOR [M]
X7201 H2B169500005 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL300 A2BB00000166 FL DISPLAY [M]
FUSE
F1 K5D631BLA012 FUSE [M]
FUSE HOLDERS
FC1 EYF52BCY FUSE CLIP [M]
FC2 EYF52BCY FUSE CLIP [M]
FUSE PROTECTORS
FP502 K5G202A00044 FUSE PROTECTOR [M]
FP600 K5G502A00039 FUSE PROTECTOR [M]
FP601 K5G502A00039 FUSE PROTECTOR [M]
JACKS
JK500 K2AA2B000011 JK AC INLET [M]
JK600 K4BC04B00086 JK RED/BLACK SPEAKER [M]
JK730 K2HC103A0024 JK HP [M]
JK740 K2HC1YYA0002 JK MUSIC PORT [M]
CHIP JUMPERS
W407 ERJ6GEY0R00V CHIP JUMPER [M]
W703 ERJ6GEY0R00V CHIP JUMPER [M]
W704 ERJ6GEY0R00V CHIP JUMPER [M]
W705 ERJ6GEY0R00V CHIP JUMPER [M]
W706 ERJ6GEY0R00V CHIP JUMPER [M]
W711 ERJ3GEY0R00V CHIP JUMPER [M]
W712 ERJ6GEY0R00V CHIP JUMPER [M]
W1006 ERJ6GEY0R00V CHIP JUMPER [M]
W1007 ERJ6GEY0R00V CHIP JUMPER [M]
W1008 ERJ6GEY0R00V CHIP JUMPER [M]
W1010 ERJ6GEY0R00V CHIP JUMPER [M]
W1011 ERJ6GEY0R00V CHIP JUMPER [M]
W1012 ERJ3GEY0R00V CHIP JUMPER [M]
W1013 ERJ6GEY0R00V CHIP JUMPER [M]
W1014 ERJ3GEY0R00V CHIP JUMPER [M]
W1016 ERJ3GEY0R00V CHIP JUMPER [M]
W1017 ERJ6GEY0R00V CHIP JUMPER [M]
W1019 ERJ3GEY0R00V CHIP JUMPER [M]
W1020 ERJ6GEY0R00V CHIP JUMPER [M]
W1021 ERJ3GEY0R00V CHIP JUMPER [M]
W1022 ERJ6GEY0R00V CHIP JUMPER [M]
W1024 ERJ6GEY0R00V CHIP JUMPER [M]
W1026 ERJ3GEY0R00V CHIP JUMPER [M]
W1028 ERJ3GEY0R00V CHIP JUMPER [M]
W1029 ERJ6GEY0R00V CHIP JUMPER [M]
W1033 ERJ3GEY0R00V CHIP JUMPER [M]
W1039 ERJ6GEY0R00V CHIP JUMPER [M]
W1045 ERJ3GEY0R00V CHIP JUMPER [M]
W1048 ERJ3GEY0R00V CHIP JUMPER [M]
W1051 ERJ3GEY0R00V CHIP JUMPER [M]
W1052 ERJ3GEY0R00V CHIP JUMPER [M]
W1121 ERJ6GEY0R00V CHIP JUMPER [M]
W1122 ERJ3GEY0R00V CHIP JUMPER [M]
W1123 ERJ6GEY0R00V CHIP JUMPER [M]
W1126 ERJ3GEY0R00V CHIP JUMPER [M]
W1135 ERJ6GEY0R00V CHIP JUMPER [M]
W1137 ERJ6GEY0R00V CHIP JUMPER [M]
81
SA-NS55E / SA-NS55EG
