6.1. Component Parts List
Note: With reference to section 25 of original service manual
for SA-PT460EB/EG-K,EG-S.
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 L6FAJCCH0007 DC FAN MOTOR [M]
2 REEX0813 22P FFC WIRE (MN-SCART) [M]
3 REEX0814 50P FFC WIRE (MN-DVD) [M]
4 REEX0815 17P FFC WIRE (MN-DAMP) [M]
5 REEX0817 7P FFC WIRE (OPU-DVD) [M]
6 REEX0820 17P FFC WIRE (PAN-MN) [M]
7 REEX0821 14P FFC WIRE (IPOD-PWRSUPP) [M]
8 REEX0822 28P FFC WIRE (PWRSUPP-MN) [M]
9 REEX0823 4P FFC WIRE (PWRBUT-MN) [M]
10 RGUX0744-K SUBWOOFER BUTTON [M]K
10 RGUX0744-S SUBWOOFER BUTTON [M]S
11 REXX0636-J 5P USB WIRE (USB-DVD) [M]
12 REXX0640-J BLACK WIRE (AC-SMPS) [M]
13 REXX0641-J RED WIRE (AC-SMPS) [M]
14 REXX0651 8P FLAT WIRE (SMPS-DAMP) [M]
15 RGB0164-S PANASONIC BADGE [M]
16 RGKX0443-K DVD LID [M]
17 RGKX0489-S FRONT ORNAMENT [M]
18 VHD1224-1 SCREW [M]
19 RYPX0258-K1 CRADLE UNIT [M]K
19 RYPX0258-S1 CRADLE UNIT [M]S
20 RGLX0160-Q LIGHTING CHIP [M]
21 RGPX0334-K3 FRONT PANEL [M]K
21 RGPX0334-S3 FRONT PANEL [M]S
22 RGPX0335B-K2 CRADLE CHASSIS [M]K
22 RGPX0335B-S2 CRADLE CHASSIS [M]S
23 RGRX0067A-C2 REAR PANEL [M]
24 RGUX0741-K1 OPEN CLOSE BUTTON [M]K
24 RGUX0741-S1 OPEN CLOSE BUTTON [M]S
25 RGUX0742-K POWER BUTTON [M]K
25 RGUX0742-S POWER BUTTON [M]S
26 RXXX0085-1J HEATSINK UNIT A [M]
27 RGUX0745-K OPERATION BUTTON [M]K
27 RGUX0745-S OPERATION BUTTON [M]S
28 RGWX0104-K VOLUME KNOB [M]K
28 RGWX0104-S VOLUME KNOB [M]S
29 RHD26046 SCREW [M]
30 RHD30007-1SJ SCREW [M]K
30 RHD30007-K2J SCREW [M]S
31 RHD30090-1 SCREW [M]
32 RHD30111-3 SCREW [M]
33 RHD30119-S SCREW [M]
34 ENG07824QRF TUNER PACK [M]
35 RHDX03001 SCREW [M]
36 RKA0059-K LEG FELT [M]
37 RKWX0279-Q FL WINDOW [M]
38 RMAX0118-1 PCB BRACKET [M]
39 RMAX0129 PANEL ANGLE [M]
40 RMAX0130 DVD LID HOLDER [M]
41 RMAX0131 MAIN PCB BRACKET B [M]
42 RMAX0132 MECHA CHASSIS [M]
43 RMBX0075 DOOR SPRING [M]
44 RMC0465 TR SPRING [M]
45 RMCX0042 EARTH SPRING [M]
46 RMCX0055 SPRING PLATE [M]
47 RMCX0057 EARTH PART (FOR USB) [M]
48 RMGX0050 CRADLE RUBBER [M]
49 RMNX0207 SMPS PCB INSULATOR [M]
50 RXQX0077 FL SHIELD PLATE UNIT [M]
51 RMNX0254 USB BRACKET [M]
52 RMNX0260 FL HOLDER [M]
53 RMNX0282A AC-IN PC SHEET A [M]
54 RMNX0282B AC-IN PC SHEET B [M]
55 RXXX0104 HEATSINK UNIT B [M]
56 RXQX0041 CUSHION ASSY [M]
57 RMNX0286 HDMI PC SHEET [M]
Ref.
No.
Part No. Part Name & Description Remarks
58 RMQX0233-K FAN COVER [M]
59 RMR0502A-W PCB SUPPORT [M]
60 RXXX0105 HEATSINK UNIT C [M]
61 RMVX0117-K CONNECTOR COVER [M]K
61 RMVX0117-S CONNECTOR COVER [M]S
62 RMX0302 DAMPER RUBBER [M]
63 RMYX0191 HEATSINK EXTRUSSION [M]
64 RMZX0038 IC INSULATOR [M]
65 RSCX0188 AC-IN SHIELD PLATE [M]
66 RKMX0141-K TOP CABINET [M]
K
66 RKMX0141-S TOP CABINET [M]
S
67 RSCX0191 HDMI SHIELD PLATE [M]
68 RMKX0144 BOTTOM CHASSIS [M]
69 XSN3+4FJ SCREW [M]
70 XTB3+10JFJ SCREW [M]
71 XTB3+8JFJ SCREW [M]
72 XTW3+8TFJ SCREW [M]
73 REXX0653-J 13P WIRE (MAINN-PWRSUPP) [M]
74 REXX0639-J 11P WIRE (SMPS-PWRSUPP) [M]
PRINTED CIRCUIT BOARDS
REPX0621F D-AMP P.C.B. [M]
(RTL)
REPX0630C MAIN/SCART/POWER SUPPLY
P.C.B.
[M]
(RTL)
INTEGRATED CIRCUITS
IC2001 RFKWPT460E IC SYSTEM CONTROL [M]
IC8651 RFKWMH32B321 IC 32MB FLASH ROM [SPG]
TRANSISTORS
Q2504 B1GDCFGA0018 TRANSISTOR [M]
Q2505 B1ABGC000005 TRANSISTOR [M]
COILS AND INDUCTORS
L5002 G0B9R5K00004 LINE FILTER [M]
L5201 G0B9R5K00004 LINE FILTER [M]
L5402 G0B9R5K00004 LINE FILTER [M]
PACKING MATERIALS
P1 RPGX1869-1 PACKING CASE [M]K
P1 RPGX1950-1 PACKING CASE [M]S
P2 RPNX0529 POLYFOAM [M]
ACCESSORIES
A3 RQTX0087-1R O/I BOOK (En) [M]
A5 RQCA0968 SPEAKER LABEL [M]
A6 XTN5+10FFJK SCREW [M]
A7 REEX0858 CTR SPK CORD A’SSY [M]
RESISTORS
R2006 ERJ3GEYJ221V 220 1/10W [M]
R2026 ERJ3GEYJ221V 220 1/10W [M]
R2052 ERJ3GEYJ221V 220 1/10W [M]
R2056 ERJ3GEYJ221V 220 1/10W [M]
R2082 ERJ3GEYJ103V 10K 1/10W [M]
R2115 ERJ3GEYJ472V 4.7K 1/10W [M]
R2174 ERJ3GEYJ682V 6.8K 1/10W [M]
R2175 ERJ3GEYJ122V 1.2K 1/10W [M]
R2176 ERJ3GEYJ333V 33K 1/10W [M]
R2184 ERJ3GEYJ272V 2.7K 1/10W [M]
R2186 ERJ3GEYJ152V 1.5K 1/10W [M]
R2187 ERJ3GEYJ122V 1.2K 1/10W [M]
R2215 ERJ3GEYJ472V 4.7K 1/10W [M]
R2274 ERJ3GEYJ682V 6.8K 1/10W [M]
R2275 ERJ3GEYJ122V 1.2K 1/10W [M]
28
SA-PT465E
