Panasonic SC-MC07

8
VQT4E49
Notes on Speakers
• These speakers do not have magnetic shielding. Do not put them near devices easily
influenced by magnetism.
• When you play at high levels for a long period, it can cause damage to the unit and decrease
the life of the unit.
• Decrease the volume when you play distorted sound to prevent damage.
Specifications
Amplifier section
RMS output power:
2 W (8 ≠) 1 kHz, 5 % THD
L ch: 1 W (8 ≠) 1 kHz, 5 % THD
R ch: 1 W (8 ≠) 1 kHz, 5 % THD
Total harmonic distortion: 0.15 % (1 kHz)
S/N ratio: 87 dB (1 kHz, 20 kHz LPF)
Speaker: φ36 mm (8 ≠) × 2
Bluetooth
®
section
Bluetooth
®
system specification:
Ver. 2.1 + EDR
Wireless equipment classification:
Class 2 (2.5 mW)
Supported profiles: A2DP
Frequency band: 2402 - 2480 MHz
(Adaptive Frequency Hopping)
Driving distance: 10 m Line of Sight
(iPhone 4, at height 1 m, in “MODE 1”)
General
Power supply:
Panasonic alkaline battery:
LR6 × 2, DC 3.0 V
USB power supply: DC 5.0 V
Operating temperature range:
0 oC to +40 oC
Operating humidity range:
20% to 80% RH (no condensation)
Dimensions (W x H x D):
103 mm x 41.9 mm x 103 mm
Mass:
Approx. 216 g (with batteries)
Approx. 170 g (without batteries)
Battery duration time:
Approx. 4 hours
(Panasonic alkaline battery LR6 Type)
Note
• Specifications are subject to change
without notice. Mass and dimensions are
approximate.
• Total harmonic distortion is measured by
the digital spectrum analyzer.
Product identification marking is located on the bottom of the unit.
