Specifications
Specifications
RMS Output Power: Dolby Digital Mode
Front Ch 125 W per channel (3 ≠), 1 kHz, 10 % THD
Surround Ch 125 W per channel (3 ≠), 1 kHz, 10 % THD
Center Ch 250 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer Ch 250 W per channel (6 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power 1000 W
FTC Output Power: Dolby Digital Mode
Front Ch 63 W per channel (3 ≠), 120 Hz to 20 kHz, 1 % THD
Surround Ch 34 W per channel (3 ≠), 120 Hz to 20 kHz, 1 % THD
Center Ch 113 W per channel (6 ≠), 120 Hz to 20 kHz, 1 % THD
Subwoofer Ch 121 W per channel (6 ≠), 45 Hz to 120 Hz, 1 % THD
Total FTC Dolby Digital mode power 428 W
Preset Memory FM 30 stations
AM 30 stations
Frequency Modulation (FM)
Frequency range 87.9 MHz to 107.9 MHz (200-kHz step)
87.5 MHz to 108.0 MHz (100-kHz step)
Antenna terminals 75 ≠ (unbalanced)
Amplitude Modulation (AM)
Frequency range 520 kHz to 1710 kHz (10-kHz step)
Digital audio input
Optical digital input Optical terminal
Sampling frequency 32 kHz, 44.1 kHz, 48 kHz
Phone jack
Terminal Stereo, 3.5 mm (
1
/
8
z
) jack
Discs played [8 cm (3
z
) or 12 cm (5
z
)]
(1) DVD (DVD-Video)
(2) DVD-RAM (DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(3) DVD-R (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(4) DVD-R DL (DVD-Video, DVD-VR)
(5) DVD-RW (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(6) iR/iRW (Video)
(7) iR DL (Video)
(8) CD, CD-R/RW (CD-DA, Video CD, SVCD
§1
, MP3
§2, 5
, WMA
§3, 5
,
JPEG
§4, 5
)
§1
Conforming to IEC62107
§2
MPEG-1 Layer 3, MPEG-2 Layer 3
§3
Windows Media Audio Ver.9.0 L3
Not compatible with Multiple Bit Rate (MBR)
§4
Exif Ver 2.1 JPEG Baseline files
Picture resolution: between 160k120 and 6144k4096 pixels (Sub
sampling is 4:0:0, 4:2:0, 4:2:2 or 4:4:4). Extremely long and narrow
pictures may not be displayed.
§5
The total combined maximum number of recognizable audio and
picture contents and groups: 4000 audio and picture contents and
400 groups.
Pick up
Wavelength (DVD/CD) 655/785 nm
Laser power (DVD/CD) CLASS II /CLASS I
Audio output (Disc)
Number of channels 5.1 ch (FL, FR, C, SL, SR, SW)
Video system NTSC
Composite video output
Output level 1 Vp-p (75 ≠)
Terminal Pin jack (1 system)
Component video output
Y output level 1 Vp-p (75 ≠)
P
B output level 0.7 Vp-p (75 ≠)
P
R output level 0.7 Vp-p (75 ≠)
Terminal Pin jack (Y: green, P
B: blue, PR: red) (1 system)
HDMI AV output
Terminal 19-pin type A connector
HDAVI Control This unit supports “HDAVI Control 3” function.
[Front\speakers\SB-HF665]
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 3 ≠
Tweeter 6 cm (2
3
/8z) Cone type
Woofer 16 cm (6
1
/2z) Cone type
Input power (IEC) 130 W (Max)
Output sound pressure 83 dB/W (1.0 m)
Frequency range 49 Hz to 28 kHz (j16 dB)
52 Hz to 26 kHz (j10 dB)
Dimensions (WtHtD) 221 mmk401 mmk244 mm
(8
11
/16zk15
25
/32zk9
19
/32z)
Mass [Weight] 3.5 kg (7.7 lbs)
[Surround\speakers\SB-HS665]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 3 ≠
Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 125 W
§6
(Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 95 Hz to 25 kHz (j16 dB)
110 Hz to 22 kHz (j10 dB)
Dimensions (WtHtD) 270 mmk94 mmk95 mm
(10
5
/8zk3
11
/16zk3
3
/4z)
Mass [Weight] 0.9 kg (1.98 lbs)
[Center\speaker\SB-PC880]
Type 1 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
1. Full range 6.5 cm (2
1
/2z) Cone type
2. Full range 6.5 cm (2
1
/2z) Cone type
Input power (IEC) 250 W
§6
(Max)
Output sound pressure 82 dB/W (1.0 m)
Frequency range 80 Hz to 25 kHz (j16 dB)
96 Hz to 22 kHz (j10 dB)
Dimensions (WtHtD) 270 mmk94 mmk95 mm
(10
5
/8zk3
11
/16zk3
3
/4z)
Mass [Weight] 1.3 kg (2.9 lbs)
[Subwoofer\SB-WVK870]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 6 ≠
Woofer 25 cm (10z) Cone type
Input power (IEC) 250 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Frequency range 48 Hz to 250 Hz (j16 dB)
50 Hz to 200 Hz (j10 dB)
Dimensions (WtHtD) 320 mmk411 mmk330 mm
(12
19
/32zk16
3
/16zk13z)
Mass [Weight] 7.2 kg (15.9 lbs)
Power supply AC 120 V, 60 Hz
Power consumption Main unit 135 W
Dimensions (WtHtD) 430 mmk63 mmk327 mm
(1
6
15
/
16
zk
2
15
/
32
zk
12
7
/
8
z
)
Mass [Weight] Main unit 3.7 kg (8.2 Ibs)
Operating temperature range 0 oC to r40 oC (r32 oF to r104 oF)
Operating humidity range 35 % to 80 % RH (no condensation)
§6
Rating with Low-cut filter equipped Amplifier
[Note]
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by a digital spectrum analyzer.
AMPLIFIER SECTION
FM/AM TUNER, TERMINALS SECTION
DISC SECTION
VIDEO SECTION
SPEAKER SECTION
GENERAL
Power consumption in standby mode approx. 0.3 W
