Specifi cations
TH-37PV500B TH-42PV500B TH-50PV500B
Power Source AC 220-240 V, 50 / 60 Hz
Power Consumption Average use : 290 W
Standby condition :
0.3 W (Without DVB recording)
16 W (With DVB recording)
Average use : 350 W
Standby condition :
0.3 W (Without DVB recording)
16 W (With DVB recording)
Average use : 470 W
Standby condition :
0.3 W (Without DVB recording)
16 W (With DVB recording)
Plasma Display panel
Drive method AC type
Aspect Ratio 16:9
Contrast Ratio 3000:1
Visible screen size
(No.of pixels)
94 cmV 106 cmV 127 cmV
818 mm (W) × 461 mm (H) ×
939 mm (diagonal)
920 mm (W) × 518 mm (H) ×
1,056 mm (diagonal)
1,106 mm (W) × 622 mm (H) ×
1,269 mm (diagonal)
737,280 (1,024 (W) × 720 (H))
[3,072 × 720 dots]
786,432 (1,024 (W) × 768 (H))
[3,072 × 768 dots]
1,049,088 (1,366 (W) × 768
(H)) [4,098 × 768 dots]
Sound
Speaker Woofer (φ 80 mm) × 2 pcs, Tweeter (16 mm × 73 mm) × 4 pcs
Audio Output 26 W (13 W + 13 W ), 10% THD
Headphones M3 (3.5 mm) Jack × 1
PC signals VGA, SVGA, XGA
SXGA ······ (compressed)
Horizontal scanning frequency
31 - 69 kHz
Vertical scanning frequency
59 - 86 Hz
XGA display
VGA, SVGA, XGA
SXGA ······ (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems /
Band name
PAL I UHF E21-68.
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR) or
NTSC disc playback from DVD player and recorder.
DVB Digital terrestrial services via UHF aerial input.
M.NTSC Playback from M.NTSC Video recorders (VCR).
NTSC (AV input only) Playback from NTSC Video recorders (VCR).
Aerial - Rear UHF
Operating Conditions Temperature : 0 °C - 40 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 (Scart connecter) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in)
AV2 (Scart connecter) 21 Pin terminal (Audio/Video in, Audio/Video out, S-Video in, Q-Link)
AV3 VIDEO RCA PIN Type × 1 1.0 Vp-p (75 Ω)
S-VIDEO Mini DIN 4-pin Y:1.0 Vp-p (75 Ω) C:0.286 Vp-p (75 Ω)
AUDIO L - R RCA PIN Type × 2 0.5 Vrms
AV4 (Scart connecter) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, S-Video in, Q-Link)
Others COMPONENT Y 1.0 Vp-p (including synchronization)
P
B, PR ±0.35 Vp-p
HDMI TYPE A Connector
PC HIGH-DENSITY D-SUB 15PIN R,G,B/0.7 Vp-p (75 Ω)
HD, VD/TTL Level 2.0 - 5.0 Vp-p (high impedance)
AUDIO L - R RCA PIN Type × 2 0.5 Vrms
Card slot SD CARD slot × 1, PC CARD slot × 1
Output AUDIO L - R RCA PIN Type × 2 0.5 Vrms (high impedance)
Dimensions ( W × H × D )
1,038 mm × 670 mm × 138 mm 1,138 mm × 730 mm × 138 mm 1,327 mm × 843 mm × 138 mm
Weight 35.0 kg Net 40.0 kg Net 52.0 kg Net
Notes:
• Design and Specifi cations are subject to change without notice. Weight and Dimensions shown are approximate.
• This equipment complies with the EMC standards listed below.
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024.
Trademark Credits
• DVB is a trademark of the DVB Digital Video Broadcasting Project (1991 to 1996).
• VGA is a trademark of International Business Machines Corporation.
• Macintosh is a registered trademark of Apple Computer, USA.
• S-VGA is a registered trademark of the Video Electronics Standard Association.
Even if no special notation has been made of company or product trademarks, these trademarks have been fully respected.
• SD Logo is a trademark.
• HDMI, the HDMI Logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing
LLC.
