English
9
■ Aerial
TV
RF cable
Aerial
●
For Digital TV, Analogue TV
●
Keep RF (aerial) cable away from the mains lead to
avoid and minimise mains interference pickup.
●
Do not place the RF cable under the TV.
●
An aerial, correct cable (75 Ω coaxial) and correct
terminating plug are required to obtain optimum
quality picture and sound.
●
If a communal aerial system is used, you may require
the correct connection cable and plug between the
wall aerial socket and the TV.
●
Your local Television Service Centre or dealer may
be able to assist you in obtaining the correct aerial
system for your particular area and the accessories
required.
●
Any matters regarding aerial installation, upgrading
of existing systems or accessories required, and
the costs incurred, are the responsibility of you, the
customer.
■ Satellite dish
New Zealand
TV
Satellite cable
Satellite dish
●
For Satellite TV
●
To ensure your satellite dish is correctly installed,
please consult your local dealer. Also consult the
received satellite broadcasting companies for details.
1 USB 1 - 3 port
2 HDMI3
3 AV IN (COMPONENT / VIDEO)
(p. 10, 11)
4 ETHERNET
(p. 10)
5 Aerial terminal
(p. 9)
Satellite terminal
(p. 9)
New Zealand
6 DIGITAL AUDIO OUT
7 HDMI1 - 2
(p. 10, 11)
●
To watch content in 4K format, use HDMI terminal.
(p. 10)
Basic connections
■ Mains lead
AC 220-240 V
50 / 60 Hz
Mains lead
(supplied)
50-inch model
Insert the mains plug firmly into place.
●
When disconnecting the mains lead,
be absolutely sure to disconnect the
mains plug from the mains socket
first.
55-inch model
65-inch model
Push until both side
tabs click
Make sure that the
mains lead is securely
fixed
To remove from the TV:
tabs
Press both tabs and pull on mains connector to
release
