101

L16002 G0C1R6KA0119 PEAKING COIL 1

L16003 G0C1R6KA0119 PEAKING COIL 1

L16004 G0C1R6KA0119 PEAKING COIL 1

L16011 G0C1R6KA0119 PEAKING COIL 1

L16012 G0C1R6KA0119 PEAKING COIL 1

L16013 G0C1R6KA0119 PEAKING COIL 1

L16014 G0C1R6KA0119 PEAKING COIL 1

L16102 J0JJC0000015 CHIP INDUCTOR 1

L16103 G0ZZ00002183 PEAKING COIL 1

L16104 J0JJC0000015 CHIP INDUCTOR 1

L16221 G0ZZ00002183 PEAKING COIL 1

L16262 G0ZZ00002183 PEAKING COIL 1

L16271 G0ZZ00002183 PEAKING COIL 1

L16301 J0JHC0000031 CHIP INDUCTOR 1

L16398 J0JJC0000015 CHIP INDUCTOR 1

L16399 J0JJC0000015 CHIP INDUCTOR 1

L16401 G0C1R4KA0118 PEAKING COIL 1

L16402 G0C1R4KA0118 PEAKING COIL 1

L16404 G0C1R4KA0118 PEAKING COIL 1

L16411 G0C1R4KA0118 PEAKING COIL 1

L16412 G0C1R4KA0118 PEAKING COIL 1

L16414 G0C1R4KA0118 PEAKING COIL 1

L16472 G0ZZ00002183 PEAKING COIL 1

L16591 G0ZZ00002183 PEAKING COIL 1

L16697 G0C102KA0187 PEAKING COIL 1

L16698 G0C681KA0187 PEAKING COIL 1

L16699 G0C331KA0187 PEAKING COIL 1

L16801 G0ZZ00002183 PEAKING COIL 1

PA5600 K5H5022A0023 FUSE 1

PA9800 K5H4022A0023 FUSE 1

PA9900 K5H5022A0023 FUSE 1

PC14951 B3PBA0000457 IC 1

PC14952 B3PBA0000457 IC 1

PC16480 B3PBA0000223 IC 1

PC16601 B3PBA0000223 IC 1

PC16602 B3PBA0000443 IC 1

PC16603 B3PBA0000223 IC 1

PC16705 B3PBA0000456 IC 1

PC16710 B3PBA0000223 IC 1

PC16896 B3PBA0000223 IC 1

PC16897 B3PBA0000223 IC 1

PCB TNPH0716ADS CIRCUIT BOARD A 1 PAVCA

PCB N0AE6JL00001 CIRCUIT BOARD P 1 PAVCA

PCB TXNC11RQTU CIRCUIT BOARD C1 1 PAVCA

PCB TXNC21RQTU CIRCUIT BOARD C2 1 PAVCA

PCB TXNC31RQTU CIRCUIT BOARD C3 1 PAVCA

PCB TXNSC1RQTUS CIRCUIT BOARD SC 1 PAVCA

PCB TXNSD1RQTU CIRCUIT BOARD SD 1 PAVCA

PCB TXNSS1RQTU CIRCUIT BOARD SS 1 PAVCA

PCB TNPA4395S CIRCUIT BOARD

SS2

1 PAVCA

PCB TNPA4396S CIRCUIT BOARD

SS3

1 PAVCA

PCB TXNSU1RQTU CIRCUIT BOARD SU 1 PAVCA

PCB TNPA4501S CIRCUIT BOARD G 1 PAVCA

PCB TNPA4139ADS CIRCUIT BOARD GS 1 PAVCA

PCB TNPA4500S CIRCUIT BOARD K 1 PAVCA

PCB TNPA4499S CIRCUIT BOARD S 1 PAVCA

Q2041 2SD0601ARL TRANSISTOR 1

Q2042 2SD0601ARL TRANSISTOR 1

Q2301 2SB0709ARL TRANSISTOR 1

Q2510 2SD0601ARL TRANSISTOR 1

Q2511 2SD0601ARL TRANSISTOR 1

Q3123 2SD0601ARL TRANSISTOR 1

Q3124 2SD0601ARL TRANSISTOR 1

Q3125 2SB0709ARL TRANSISTOR 1

Q4016 B1CFNG000001 FET 1

Q4017 2SD0601ASL TRANSISTOR 1

Safety Ref. No. Part No. Part Name &

Description

Pcs Remarks

Q4502 2SD0601ARL TRANSISTOR 1

Q4503 2SD0601ARL TRANSISTOR 1

Q4514 2SB0709ARL TRANSISTOR 1

Q4515 2SB0709ARL TRANSISTOR 1

Q4516 2SB0709ARL TRANSISTOR 1

Q4517 2SB0709ARL TRANSISTOR 1

Q4522 2SD0601ARL TRANSISTOR 1

Q4523 2SD0601ARL TRANSISTOR 1

Q5522 2SB0709ARL TRANSISTOR 1

Q5600 B1MBEDA00015 FET 1

Q5601 B1MBDDA00003 FET 1

Q5602 B1MBDDA00003 FET 1

Q5603 2SD0601ARL TRANSISTOR 1

Q5604 2SD0601ARL TRANSISTOR 1

Q5684 2SB0709ARL TRANSISTOR 1

Q8300 2SB0709ARL TRANSISTOR 1

Q9010 2SD0601ARL TRANSISTOR 1

Q9044 2SD0601ARL TRANSISTOR 1

Q9046 2SD0601ARL TRANSISTOR 1

Q9057 2SD0601ARL TRANSISTOR 1

Q9058 2SD0601ARL TRANSISTOR 1

Q9301 2SD0601ARL TRANSISTOR 1

Q9302 2SD0601ARL TRANSISTOR 1

Q9805 2SD0601ARL TRANSISTOR 1

Q9806 2SD0601ARL TRANSISTOR 1

Q9807 B1MBDDA00003 FET 1

Q9808 B1MBDDA00015 FET 1

Q9809 B1MBDDA00003 FET 1

Q14961 2SD0601ARL TRANSISTOR 1

Q14962 2SD0601ARL TRANSISTOR 1

Q16001 B1JAEN000002 TRANSISTOR 1

Q16002 B1JAEN000002 TRANSISTOR 1

Q16021 B1JAEN000002 TRANSISTOR 1

Q16022 B1JAEN000002 TRANSISTOR 1

Q16041 B1JAEN000003 TRANSISTOR 1

Q16051 B1JAEN000003 TRANSISTOR 1

Q16102 2SK399800L FET 1

Q16104 2SK399800L FET 1

Q16141 B1HFPFA00001 TRANSISTOR 1

Q16161 B1HFPFA00001 TRANSISTOR 1

Q16171 B1ABRD000003 TRANSISTOR 1

Q16172 B1ADRD000001 TRANSISTOR 1

Q16181 B1ABRD000003 TRANSISTOR 1

Q16182 B1ADRD000001 TRANSISTOR 1

Q16191 B1HFPFA00001 TRANSISTOR 1

Q16251 2SD0601ARL TRANSISTOR 1

Q16280 2SD0601ARL TRANSISTOR 1

Q16301 B1CBGD000001 FET 1

Q16302 B1CFNG000001 FET 1

Q16304 2SB0709ARL TRANSISTOR 1

Q16331 B1CERL000012 FET 1

Q16335 B1CERL000012 FET 1

Q16339 2SK417300L FET 1

Q16401 B1JAEN000002 TRANSISTOR 1

Q16402 B1JAEN000002 TRANSISTOR 1

Q16403 B1JAEN000002 TRANSISTOR 1

Q16421 B1JAEP000002 TRANSISTOR 1

Q16422 B1JAEP000002 TRANSISTOR 1

Q16441 B1JAEN000003 TRANSISTOR 1

Q16451 B1JAEP000003 TRANSISTOR 1

Q16471 B1ABCF000231 TRANSISTOR 1

Q16501 B1HFPFA00001 TRANSISTOR 1

Q16521 B1HFPFA00001 TRANSISTOR 1

Q16531 B1ABRD000003 TRANSISTOR 1

Q16532 B1ADRD000001 TRANSISTOR 1

Q16551 B1ABRD000003 TRANSISTOR 1

Q16552 B1ADRD000001 TRANSISTOR 1

Q16581 B1ABCF000231 TRANSISTOR 1

Q16601 B1DEET000002 FET 1

Q16602 2SD0601AQL TRANSISTOR 1

Q16603 2SB0709ARL TRANSISTOR 1

Q16604 B1CHPM000001 FET 1

Q16605 2SB0709ARL TRANSISTOR 1

Safety Ref. No. Part No. Part Name &

Description

Pcs Remarks
